IN4004 Rectifier Diode General Purpose Rectifier PLASTIC SILICON RECTIFIER

: Large Image : IN4004 Rectifier Diode General Purpose Rectifier PLASTIC SILICON RECTIFIER

Product Details:

Place of Origin:	original factory
Brand Name:	Anterwell
Certification:	new & original
Model Number:	IN4004

Payment & Shipping Terms:

Minimum Order Quantity:	100pcs
Price:	Negotiate
Packaging Details:	Please contact me for details
Delivery Time:	1 day
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	72000pcs

Contact Now

Detailed Product Description

Maximum Recurrent Peak Reverse Voltage:	400VV	Maximum RMS Voltage:	280 V
Maximum DC Blocking Voltage:	400 V	Maximum Overload Surge 8.3 Ms Single Half Sine-wave:	50 A
Typical Junction Capacitance:	30 PF	Operating And Storage Temperature:	-65 To +175 ℃
Highlight:	diode rectifier circuit , bridge rectifier circuit

IN4001 thru IN4007

PLASTIC SILICON RECTIFIER

VOLTAGE RANGE 50 TO 1000 Volts

CURRENT 1.0 Ampere

FEATURE

• Low forward voltage

• High current capability

• Low leakage current

• High surge capability

• Low cost

MECHANICAL DATA

• Case:Molded plastic use UL 94V-0 recognized Flame retardant epoxy

• Terminals:Axial leads, solderable per MIL-STD-202, method 208

• Polarity:Color band denotes cathode

• Mounting Position:Any

MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS

Single-phase, half-wave, 60Hz, resistive or inductive load

	IN4001	IN4002	IN4003	IN4004	IN4005	IN4006	IN4007	Unit
Maximum Recurrent Peak Reverse Voltage	50	100	200	400	600	800	1000	V
Maximum RMS Voltage	35	70	140	280	420	560	700	V
Maximum DC Blocking Voltage	50	100	200	400	600	800	1000	V
Maximum Average Forward Rectified Current 3/8 Lead Length at T_A =75 ℃	1.0							A
Maximum Overload Surge 8.3 ms single half sine-wave	50							A
Maximum Forward Voltage at 1.0A AC and 25 ℃	1.1							V
Maximum Full Load Reverse Current, Full Cycle Average 0 at 75 ℃ Ambient	30							μA
Maximum DC Reverse Current at 25 ℃ at Rated DC Blocking Voltage at 75 ℃	5.0 50.0							μA
Typical Junction Capacitance (Note 1)	30							pF
Operating and Storage Temperature Range	-65 to +175							℃

Notes :

1. Measured at 1.0MHz and applied reverse voltage of 4.0 VDC.

* JEDEC Registered Value.
