Low Noise, Cascadable Silicon Bipolar MMIC Amplifier INA-03184

Features

• Cascadable 50 Ω Gain Block

• Low Noise Figure: 2.6 dB Typical at 1.5 GHz

• High Gain: 25 dB Typical at 1.5 GHz

• 3 dB Bandwidth: DC to 2.5 GHz

• Unconditionally Stable (k>1)

• Low Power Dissipation: 10 mA Bias

• Low Cost Plastic Package

The INA series of MMICs is fabricated using HP’s 10 GHz fT, 25␣ GHz f _MAX, ISOSAT™-I silicon bipolar process which uses nitride self-alignment, submicrometer lithography, trench isolation, ion implantation, gold metallization and polyimide intermetal dielectric and scratch protection to achieve excellent performance, uniformity and reliability.

Typical Biasing Configuration

Note: 1. VSWR can be improved by bypassing a 100–120 Ω bias resistor directly to ground. See AN-S012: Low Noise Amplifiers.

84 Plastic Package

Absolute Maximum Ratings

Notes:

1. Permanent damage may occur if any of these limits are exceeded.

2. Derate at 10 mW/°C for TC > 130°C.
