M3024m 4 Pin Sop Random Phase Triac Single Chip 16Bit Cmos Microcomputer Cfl Circuit Component

M3024M 4 PIN SOP RANDOM-PHASE TRIAC SINGLE-CHIP 16-BIT CMOS MICROCOMPUTER cfl circuit component

Features

• CPU .................................................... 16-bit

(including a hardware multiplier)

• Number of instructions ........................ 91

• Shortest instruction execution time ..... 83ns f(XIN)=12MHz

• USB Features:..................................... Five endpoint pairs (IN/OUT) FIFO Sizes (endpoints 0-4):32,128, 32, 32, 32 Conforms to USB V1.1 Specification

• USB Transceiver ................................. Conforms to USB V1.1 Specification-Internal Vref

• Frequency Synthesizer........................ PLL for 48MHz clock

• Memory capacity (mask device):......... ROM (40K, 48K) / RAM (3.0 K)

• Memory capacity (OTP device):.......... PROM (128K) / RAM (5K)

• Supply Voltage .................................... 4.1 to 5.25V f(XIN)=12MHz)

• Interrupts............................................. 21 internal and 4 external interrupt sources, 4 software interrupt sources; 7 levels (including key input interrupt X 16)

 Description

The M30240 group is a 16-bit microcomputer based on the M16C family core technology. They are single-chip USB peripheral microcontrollers based on the Universal Serial Bus (USB) Version 1.1 specification. They are packaged in an 80-pin, molded plastic QFP. These single-chip microcontrollers operate using sophisticated instructions featuring a high level of instruction efficiency, making them capable of executing instructions at high speed. They also feature a built-in multiplier and DMAC, making them ideal for controlling office communications, industrial equipment, and other high-speed processing applications.

Block Diagram
