Product Details:
Payment & Shipping Terms:
|
| Maximum Repetitive Peak Reverse Voltage: | 100 V | Working Peak Reverse Voltage: | 100 V |
|---|---|---|---|
| Maximum DC Blocking Voltage: | 100 V | Peak Forward Surge Current: | 150 A |
| Voltage Rate Of Change (rated VR): | 10,000 V/µs | Operating Junction And Storage Temperature: | –65 To +175 °C |
| Highlight: | diode rectifier circuit,bridge rectifier circuit |
||
MBR10H100CT, MBRF10H100CT & MBRB10H100CT Series
Dual High-Voltage Schottky Rectifiers
Rev. Voltage 90 to 100V
Forward Current 10A
Features
• Plastic package has Underwriters Laboratory Flammability Classification 94V-0
• Dual rectifier construction, positive center tap
• Metal silicon junction, majority carrier conduction
• Low power loss, high efficiency
• Guardring for overvoltage protection
• For use in low voltage, high frequency inverters, free wheeling, and polarity protection applications
Mechanical Data
Case: JEDEC TO-220AB, ITO-220AB & TO-263AB molded plastic body
Terminals: Plated leads, solderable per MIL-STD-750, Method 2026
High temperature soldering guaranteed: 250°C/10 seconds, 0.25" (6.35mm) from case
Polarity: As marked
Mounting Position: Any
Mounting Torque: 10 in-lbs maximum
Weight: 0.08oz., 2.24g
Maximum Ratings (TC = 25°C unless otherwise noted)
| Parameter | Symbol | MBR10H90CT | MBR10H100CT | Unit |
|---|---|---|---|---|
| Maximum repetitive peak reverse voltage | VRRM | 90 | 100 | V |
| Working peak reverse voltage | VRWM | 90 | 100 | V |
| Maximum DC blocking voltage | VDC | 90 | 100 | V |
|
Maximum average forward rectified current Total device at TC = 105°C Per leg |
IF(AV) |
10 5 |
A | |
|
Peak forward surge current 8.3ms single half sine-wave superimposed on rated load (JEDEC Method) per leg |
IFSM | 150 | A | |
| Peak repetitive reverse current per leg at tp = 2µs, 1KHZ | IRRM | 0.5 | A | |
| Voltage rate of change (rated VR) | dv/dt | 10,000 | V/µs | |
| Operating junction and storage temperature range | TJ, TSTG | –65 to +175 | °C | |
|
RMS Isolation voltage (MBRF type only) from terminals to heatsink with t = 1 second, RH ≤ 30% |
VISOL |
4500 (1) 3500 (2) 1500 (3) |
V | |
Notes:
(1) Clip mounting (on case), where lead does not overlap heatsink with 0.110” offset
(2) Clip mounting (on case), where leads do overlap heatsink
(3) Screw mounting with 4-40 screw, where washer diameter is ≤ 4.9 mm (0.19”)
