MPC562MZP56 electronic integrated circuit Motorola MPC500 RISC Microcontroller



MPC561/MPC562 / MPC563/MPC564 RISC MCU Including Peripheral Pin Multiplexing with Flash and Code Compression Options



Features

The MPC561/MPC562 / MPC563/MPC564 are members of the Motorola MPC500 RISC Microcontroller family. As shown in the block diagram, they are composed of:



• High performance CPU system

  — High performance core

      • Single issue integer core

      • Compatible with PowerPC instruction set architecture

      • Precise exception model

      • Floating point

      • Extensive system development support

        — On-chip watchpoints and breakpoints

        — Program flow tracking

        — Background debug mode (BDM)

        — IEEE-ISTO Nexus 5001-1999 Class 3 Debug Interface

  — MPC500 system interface (USIU, BBC, L2U)

  — Fully static design

  — Four major power saving modes

      • On, doze, sleep, deep-sleep and power-down

  — 32-Kbyte static RAM (CALRAM)

  — 512-Kbyte flash (UC3F) on MPC563/MPC564

  — General-purpose I/O support

      • On address (24) and data (32) pins

      • 16 GPIO in MIOS14

      • Many peripheral pins can be used as GPIO when not used as primary functions

      • 2.6-V outputs on external bus pins

• PPM (peripheral pin multiplexing with parallel-to-serial driver) module

• Available in package or die

  — Plastic ball grid array (PBGA) packaging



Key Feature Details



MPC500 System Interface (USIU)

• System configuration and protection features:

  — Periodic-interrupt timer

  — Bus monitor

  — Software watchdog timer

  — Real-time clock (RTC)

  — Decrementer

  — Time base

• Clock synthesizer

• Power management

• Reset controller

• External bus interface that tolerates 5-V inputs, provides 2.6-V outputs and supports

  multiple-master designs

• Enhanced interrupt controller that supports up to eight external and 40 internal interrupts,

  simplifies the interrupt structure and decreases interrupt processing time

• USIU supports dual mapping to map part of one internal/external memory to another external memory

• USIU supports dual mapping of flash on MPC563 and MPC564 to move part of internal flash memory

  to external bus for development

• External bus, supporting non-wraparound burst for instruction fetches, with up to 8 instructions

  per memory cycle



Burst Buffer Controller (BBC) Module

• Support for enhanced interrupt controller (EIC)

• Support for enhanced exception table relocation feature

• Branch target buffer

• Contains 2-Kbytes of decompression RAM (DECRAM) for code compression.

  This RAM may also be used as general-purpose RAM when code compression feature not used.



Flexible Memory Protection Unit

• Flexible memory protection units (MPU) in BBC and L2U

• Default attributes available in one global entry

• Attribute support for speculative accesses

• Up to eight memory regions are supported, four for data and four for instructions



Memory Controller

• Four flexible chip selects via memory controller

• 24-bit address and 32-bit data buses

• 4-Kbyte to one 16-Mbyte (data) or four-Gbyte (instruction) region size support

• Supports enhanced external burst

• Up to eight-beat transfer bursts, two-clock minimum bus transactions

• Use with SRAM, EPROM, flash and other peripherals

• Byte selects or write enables

• 32-bit address decodes with bit masks

• Four regions
