Product Details:
Payment & Shipping Terms:
|
| VRM: | 100 V | VR(RMS): | 53 V |
|---|---|---|---|
| IFM: | 300 MA | IO: | 200 MA |
| Pd: | 350 MW | ||
| Highlight: | diode rectifier circuit,signal schottky diode |
||
Features
• Fast Switching Speed
• Surface Mount Package Ideally Suited for Automatic Insertion
• For General Purpose Switching Applications
• High Conductance
• Lead Free/RoHS Compliant (Note 3)
• Qualified to AEC-Q101 Standards for High Reliability
Mechanical Data
• Case: SOT-23
• Case Material: Molded Plastic. UL Flammability Classification Rating 94V-0
• Moisture Sensitivity: Level 1 per J-STD-020C
• Terminals: Solderable per MIL-STD-202, Method 208
• Lead Free Plating (Matte Tin Finish annealed over Alloy 42 leadframe).
• Polarity: See Diagram
• Marking Information: KA6, KA2, K5D; See Page 3
• Ordering Information: See Page 3
• Weight: 0.008 grams (approximate)
Maximum Ratings @TA = 25°C unless otherwise specified
| Characteristic | Symbol | Value | Unit |
| Non-Repetitive Peak Reverse Voltage | VRM | 100 | V |
| Peak Repetitive Reverse Voltage Working Peak Reverse Voltage DC Blocking Voltage |
VRRM VRWM VR |
75 | V |
| RMS Reverse Voltage | VR(RMS) | 53 | V |
| Forward Continuous Current (Note 1) | IFM | 300 | mA |
| Average Rectified Output Current (Note 1) | IO | 200 | mA |
|
Non-Repetitive Peak Forward Surge Current @ t = 1.0μs @ t = 1.0s |
IFSM |
2.0 1.0 |
A |
| Power Dissipation (Note 1) | Pd | 350 | mW |
| Thermal Resistance Junction to Ambient Air (Note 1) | RθJA | 357 | °C/W |
| Operating and Storage Temperature Range Tj , | TSTG | -65 to +150 | °C |
