PS9113 Electronic IC Chip INTELLIGENT POWER MODULE 5-PIN SOP PHOTOCOUPLER

: Large Image : PS9113 Electronic IC Chip INTELLIGENT POWER MODULE 5-PIN SOP PHOTOCOUPLER

Product Details:

Place of Origin:	original factory
Brand Name:	Anterwell
Certification:	new & original
Model Number:	PS9113

Payment & Shipping Terms:

Minimum Order Quantity:	10pcs
Price:	Negotiate
Packaging Details:	Please contact me for details
Delivery Time:	1 day
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	9000pcs

Contact Now

Detailed Product Description

Forward Current:	25 MA	Reverse Voltage:	5 V
Supply Voltage:	−0.5 To +35 V	Output Voltage:	−0.5 To +35 V
Output Current:	15 MA	Power Dissipation:	100 MW
Highlight:	electronic integrated circuit , linear integrated circuits

PHOTOCOUPLER PS9113

1 Mbps, OPEN COLLECTOR OUTPUT HIGH CMR, INTELLIGENT POWER MODULE 5-PIN SOP PHOTOCOUPLER

DESCRIPTION

The PS9113 is an optically coupled isolator containing a GaAlAs LED on the input side and a photo diode and a signal processing circuit on the output side on one chip.

The PS9113 is specified high CMR, high CTR and pulse width distortion with operating temperature. It is suitable for IPM drive.

FEATURES

• High instantaneous common mode rejection voltage (CM_H, CM_L = ±15 kV/µs MIN.)

• Small package (5-pin SOP)

• High-speed response (t_PHL = 500 ns MAX., t_PLH = 750 ns MAX.)

• Maximum propagation delays (t_PLH − t_PHL = 270 ns TYP.)

• Pulse width distortion ( t_PHL − t_PLH = 270 ns TYP.)

• Ordering number of taping product: PS9113-F3, F4: 2 500 pcs/reel

• Pb-Free product

• Safety standards

• UL approved: File No. E72422

• DIN EN60747-5-2 (VDE0884 Part2) approved: No. 40008902 (Option)

PS9113 Electronic IC Chip INTELLIGENT POWER MODULE 5-PIN SOP PHOTOCOUPLER

APPLICATIONS

• IPM Driver

• General purpose inverter

ABSOLUTE MAXIMUM RATINGS (T_A = 25°C, unless otherwise specified)

Parameter		Symbol	Ratings	Unit
Diode	Forward Current^*1	I_F	25	mA
Diode	Reverse Voltage	V_R	5	V
Detector	Supply Voltage	V_CC	−0.5 to +35	V
	Output Voltage	V_O	−0.5 to +35	V
	Output Current	I_O	15	mA
	Power Dissipation^*2	P_C	100	mW
Isolation Voltage^*3		BV	2500	Vr.m.s.
Operating Ambient Temperature		T_A	−40 to +100	°C
Storage Temperature		Tstg	−55 to +125	°C

*1 Reduced to 0.33 mA/°C at TA = 70°C or more.

*2 Reduced to 1.9 mW/°C at TA = 70°C or more.

*3 AC voltage for 1 minute at TA = 25°C, RH = 60% between input and output. Pins 1-2 shorted together, 3-4 shorted together.
