SN74LS74AN Electronic IC Chips DUAL D-TYPE POSITIVE-EDGE-TRIGGERED FLIP-FLOPS

: Large Image : SN74LS74AN Electronic IC Chips DUAL D-TYPE POSITIVE-EDGE-TRIGGERED FLIP-FLOPS

Product Details:

Place of Origin:	original factory
Brand Name:	Anterwell
Certification:	new & original
Model Number:	SN74LS74AN

Payment & Shipping Terms:

Minimum Order Quantity:	10pcs
Price:	Negotiate
Packaging Details:	Please contact me for details
Delivery Time:	1 day
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	8500pcs

Contact Now

Detailed Product Description

Input HIGH Voltage:	2.0 V	Input LOW Voltage:	0.8 V
Input Clamp Diode Voltage:	–0.65 V	Output HIGH Voltage:	3.5 V
Output Short Circuit Current:	–20 To –100 MA	Power Supply Current:	8.0 MA
Highlight:	electronic integrated circuit , linear integrated circuits

SN74LS74A

DUAL D-TYPE POSITIVE-EDGE-TRIGGERED FLIP-FLOPS

LOW POWER SCHOTTKY

The SN74LS74A dual edge-triggered flip-flop utilizes Schottky TTL circuitry to produce high speed D-type flip-flops. Each flip-flop has individual clear and set inputs, and also complementary Q and Q outputs.

Information at input D is transferred to the Q output on the positive-going edge of the clock pulse. Clock triggering occurs at a voltage level of the clock pulse and is not directly related to the transition time of the positive-going pulse. When the clock input is at either the HIGH or the LOW level, the D input signal has no effect.

SN74LS74AN Electronic IC Chips DUAL D-TYPE POSITIVE-EDGE-TRIGGERED FLIP-FLOPS

GUARANTEED OPERATING RANGES

Symbol	Parameter	Min	Typ	Max	Unit
V_CC	Supply Voltage	4.75	5.0	5.25	V
T_A	Operating Ambient Temperature Range	0	25	70	°C
I_OH	Output Current – High			-0.4	mA
I_OL	Output Current – Low			8.0	mA

SN74LS74AN Electronic IC Chips DUAL D-TYPE POSITIVE-EDGE-TRIGGERED FLIP-FLOPS
