SUM110P06-07L Power Mosfet Transistor P-Channel 60-V (D-S) 175℃ MOSFET

: Large Image : SUM110P06-07L Power Mosfet Transistor P-Channel 60-V (D-S) 175℃ MOSFET

Product Details:

Place of Origin:	original factory
Brand Name:	Anterwell
Certification:	new & original
Model Number:	SUM110P06-07L

Payment & Shipping Terms:

Minimum Order Quantity:	10pcs
Price:	Negotiate
Packaging Details:	Please contact me for details
Delivery Time:	1 day
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	9500pcs

Contact Now

Detailed Product Description

Drain-Source Voltage:	−60 V	Gate-Source Voltage:	±20 V
Pulsed Drain Current:	−240 A	Avalanche Current:	−75 A
Single Pulse Avalanche Energy:	281 MJ	Operating Junction And Storage Temperature:	−55 To 175 ℃
Highlight:	power mosfet ic , silicon power transistors

SUM110P06-07L

P-Channel 60-V (D-S) 175℃ MOSFET

FEATURES

• TrenchFET Power MOSFET

• New Package with Low Thermal Resistance

APPLICATIONS

• Automotive

− 12-V Boardnet

− High-Side Switches

− Motor Drives

SUM110P06-07L Power Mosfet Transistor P-Channel 60-V (D-S) 175℃ MOSFET

ABSOLUTE MAXIMUM RATINGS (T_C = 25℃ UNLESS OTHERWISE NOTED)

Parameter		Symbol	Limit	Unit
Drain-Source Voltage		V_DS	−60	V
Gate-Source Voltage		V_GS	±20	V
Continuous Drain Current^d (T_J = 175℃)	T_C = 25℃	I_D	−110	A
Continuous Drain Current^d (T_J = 175℃)	T_C =125℃	I_D	−95	A
Pulsed Drain Current		I_DM	−240	A
Avalanche Current	L = 0.1 mH	I_AS	-75	A
Single Pulse Avalanche Energy^a	L = 0.1 mH	E_AS	281	mJ
Power Dissipation	T_C = 25℃	P_D	375^c	W
Power Dissipation	T_A = 25℃^b	P_D	3.75	W
Operating Junction and Storage Temperature Range		T_J, Tstg	−55 to 175	℃

Notes:

a. Duty cycle 1%.

b. When mounted on 1” square PCB (FR-4 material).

c. See SOA curve for voltage derating.

d. Limited by package.
