Product Details:
Payment & Shipping Terms:
|
| Collector-Emitter Breakdown Voltage: | 50 Vdc | Collector-Base Breakdown Voltage: | 60 Vdc |
|---|---|---|---|
| Emitter-Base Breakdown Voltage: | 5 Vdc | Collector Cutoff Current: | 0.1 UAdc |
| Emitter Cutoff Current: | 0.1 UAdc | Package: | TO-92 |
| Highlight: | multi emitter transistor,silicon power transistors |
||
2SC1815-O
2SC1815-Y
2SC1815-GR
2SC1815-BL
NPN Silicon Epitaxial Transistor
Features
• 2SC1815 is NPN Silicon Epitaxial Transistor Designed for RF,
AF Amplifier and General Purpose Applications.
• Capable of 0.4Watts of Power Dissipation.
• Collector-current 0.15A
• Collector-base Voltage 60V
• Marking : C1815
• Epoxy meets UL 94 V-0 flammability rating
• Moisure Sensitivity Level 1
• Lead Free Finish/Rohs Compliant ("P"Suffix designates RoHS Compliant. See ordering information)
• Operating and storage junction temperature range:-55o C to +125o C
Electrical Characteristics @ 25℃ Unless Otherwise Specified
| Symbol | Parameter | Min | Max | Units |
|---|---|---|---|---|
| OFF CHARACTERISTICS | ||||
| V(BR)CEO | Collector-Emitter Breakdown Voltage* (IC=0.1mAdc, IB=0) | 50 | Vdc | |
| V(BR)CBO | Collector-Base Breakdown Voltage (IC=100uAdc, IE=0) | 60 | Vdc | |
| V(BR)EBO | Emitter-Base Breakdown Voltage (IE=100uAdc,IC=0) | 5 | Vdc | |
| ICBO | Collector Cutoff Current (VCB=60Vdc, IE=0Adc) | 0.1 | uAdc | |
| ICEO | Collector Cutoff Current (VCB=50Vdc, IE=0Adc) | 0.1 | uAdc | |
| IEBO | Emitter Cutoff Current (VEB=5.0Vdc, IC=0Adc) | 0.1 | uAdc | |
| ON CHARACTERISTICS | ||||
| hFE(1) | DC Current Gain* (IC=2.0mAdc, VCE=6.0Vdc) | 70 | 700 | |
| VCE(sat) | Collector-Emitter Saturation Voltage (IC=100mAdc, IB=10mAdc) | 0.25 | Vdc | |
| VBE(sat) | Base-Emitter Saturation Voltage (IC=100mAdc, IB=10mAdc) | 1.0 | Vdc | |
| VBE | Base-Emitter Voltage (IE=310mAdc) | -- | 1.45 | Vdc |
| SMALL-SIGNAL CHARACTERISTICS | ||||
| fT | Transistor Frequency (IC=1.0mAdc, VCE=10Vdc, f=30MHz) | 80 | MHz | |
