Product Details:
Payment & Shipping Terms:
|
| Category Temp.: | –55 ˚C To +85 ˚C | Rated Voltage: | 250 VDC |
|---|---|---|---|
| Capacitance Range: | 0.0010 µF To 0.12 µF (E12) | Capacitance Tolerance: | ±5 %(J) |
| Highlight: | multilayer ceramic chip capacitors,smd ceramic capacitor |
||
Plastic Film Capacitors
Stacked Metallized PEN Film Chip Capacitor
Type:ECWU(V16)
Stacked metallized PEN film dielectric with simple moldless construction
Features
• Small in size
• For reflow soldering
• RoHS directive compliant
Recommended Applications
• DC Blocking for xDSL
Explanation of Part Numbers
Specifications
|
Category temp.range (Including temperature-rise on unit surface) |
–55 ˚C to +85 ˚C |
| Rated voltage | 250 VDC |
| Capacitance range | 0.0010 µF to 0.12 µF (E12) |
| Capacitance tolerance | ±5 %(J) |
| Withstand voltage | Between terminals 400 VDC 60 s |
| Dissipation factor (tan δ) | tan δ <=1.0 % (20 ˚C, 1 kHz) |
| Insulation resistance (IR) | IR>=3000 MΩ (20 ˚C, 100 VDC, 60 s) |
| Soldering conditions | Reflow soldering : 240 ˚C max. and 60 sec max. at more than 220 ˚C (Temp. at cap. surface) (Please consult us for Reflow 250 ˚C max product.) |
❈ Application of this capacitor is limited to DC Blocking for xDSL, such as ADSL.
❈ Please consult us for 400 VDC rating product.
Construction
Dimensions in mm (not to scale)
