IXFN38N100Q2 Mosfet Power Module thyristor diode module N-Channel MOSFET

: Large Image : IXFN38N100Q2 Mosfet Power Module thyristor diode module N-Channel MOSFET

Product Details:

Place of Origin:	original factory
Brand Name:	Anterwell
Certification:	new & original
Model Number:	IXFN38N100Q2

Payment & Shipping Terms:

Minimum Order Quantity:	10pcs
Price:	Negotiate
Packaging Details:	Please contact me for details
Delivery Time:	1 day
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	6000pcs

Contact Now

Detailed Product Description

VDSS:	1000 V	VDGR:	1000 V
VGS:	±30 V	VGSM:	±40 V
PD:	890 W	Weight:	30 G
Highlight:	thyristor diode module , low voltage power mosfet

IXFN38N100Q2

HiPerFET^TM Power MOSFET

N-Channel Enhancement Mode Avalanche Rated, Low Q_g , Low Intrinsic R_g High dV/dt, Low t_rr

V_DSS = 1000 V

I_D25 = 38 A

R_DS(on)= 0.25 Ω

t_rr ≤ 300 ns

IXFN38N100Q2 Mosfet Power Module thyristor diode module N-Channel MOSFET

Features

• Double metal process for low gate resistance

• miniBLOC, with Aluminium nitride isolation

• Unclamped Inductive Switching (UIS) rated

• Low package inductance

• Fast intrinsic Rectifier

Applications

• DC-DC converters

• Switched-mode and resonant-mode power supplies

• DC choppers

• Pulse generators

Advantages

• Easy to mount

• Space savings

• High power density

Maximum Ratings

Symbol	Test Conditions	MAX.	UNIT
V_DSS	T_J = 25°C to 150°C	1000	V
V_DGR	T_J = 25°C to 150°C; R_GS = 1 MΩ	1000	V
V_GS	Continuous	±30	V
V_GSM	Transient	±40	V
I_D25	T_C = 25°C	38	A
I_DM	T_C= 25°C, pulse width limited by T_JM	152	A
I_AR	T_C = 25°C	38	A
E_AR	T_C = 25°C	60	mJ
E_AS	T_C = 25°C	5.0	J
dv/dt	I_S ≤ I_DM, di/dt ≤ 100 A/µs, V_DD ≤ V_DSS T_J ≤ 150°C, R_G = 2 Ω	20	V/ns
P_D	T_C = 25°C	890	W
T_J		-55 ... +150	°C
T_JM		150	°C
T_stg		-55 ... +150	°C
V_ISOL	50/60 Hz, RMS, t = 1 minute	2500	V
M_d	Mounting torque Terminal connection torque	1.5/13 1.5/13	Nm/lb.in. Nm/lb.in.
