Product Details:
Payment & Shipping Terms:
|
| RDS(on)1: | 70mΩ | RDS(on)2: | 95mΩ |
|---|---|---|---|
| VGS(off): | 2.0V | IGSS: | ±10µA |
| Highlight: | power mosfet ic,multi emitter transistor |
||
4 SWITCHING N-CHANNEL POWER MOS FET INDUSTRIAL USE NPN Epitaxial Silicon Transistor
PACKAGE DIMENSIONS
(in millimeter)
DESCRIPTION
The 2SK2414 is N-Channel MOS Field Effect Transistor
designed for high voltage switching applications.
FEATURES
• Low On-Resistance
RDS(on)1 = 70 mΩ MAX. (@ VGS = 10 V, ID = 5.0 A)
RDS(on)2 = 95 mΩ MAX. (@ VGS = 4 V, ID = 5.0 A)
• Low Ciss Ciss = 840 pF TYP.
• Built-in G-S Gate Protection Diodes
• High Avalanche Capability Ratings
QUALITY GRADE
Standard Please refer to "Quality grade on NEC Semiconductor Devices" (Document number IEI-1209) published by NEC Corporation to know the specification of quality grade on the devices and its recommended applications.
ABSOLUTE MAXIMUM RATINGS (TA = 25 °C)
| Drain to Source Voltage | VDSS | 60 | V |
| Gate to Source Voltage | VGSS | ±20 | V |
| Drain Current (DC) | ID(DC) | ±10 | A |
| Drain Current (pulse)* | ID(pulse) | ±40 | A |
| Total Power Dissipation (Tc = 25 ˚C) | PT1 | 20 | W |
| Total Power Dissipation (TA = 25 ˚C) | PT2 | 1.0 | W |
| Channel Temperature | Tch | 150 | °C |
| Storage Temperature | Tstg | –55 to +150 | °C |
| Single Avalanche Current** | IAS | 10 | A |
| Single Avalanche Energy** | EAS | 10 | mJ |
* PW ≤ 10 µs, Duty Cycle ≤ 1 %
** Starting Tch = 25 ˚C, RG = 25 Ω, VGS = 20 V → 0
TYPICAL CHARACTERISTICS (TA = 25 °C)
