FLASH fiscal memory Programmable IC Chips MX25L512MC-12G 512K-BIT [x 1] CMOS SERIAL

: Large Image : FLASH fiscal memory Programmable IC Chips MX25L512MC-12G 512K-BIT [x 1] CMOS SERIAL

Product Details:

Place of Origin:	CN
Brand Name:	MCNIX
Certification:	Original
Model Number:	MX25L512MC-12G

Payment & Shipping Terms:

Minimum Order Quantity:	10 PCS
Price:	Please contact me for details
Packaging Details:	contact us for more details
Delivery Time:	1 day
Payment Terms:	T/T, Western Union,Paypal
Supply Ability:	15000

Contact Now

Detailed Product Description

CS#:	Chip Select	SI:	Serial Data Input
SO:	Serial Data Output	SCLK:	Clock Input
WP#:	Write Protection
Highlight:	ic programmer circuit , programmable audio chip

MX25L512MC-12G 512K-BIT [x 1] CMOS SERIAL FLASH fiscal memory

GENERAL

• Serial Peripheral Interface (SPI) compatible

-- Mode 0 and Mode 3

• 524,288 x 1 bit structure

• 16 Equal Sectors with 4K byte each

- Any Sector can be erased individually

• Single Power Supply Operation

- 2.7 to 3.6 volt for read, erase, and program operations

• Latch-up protected to 100mA from -1V to Vcc +1V

PERFORMANCE

• High Performance

- Fast access time: 85MHz serial clock (15pF + 1TTL Load) and 66MHz serial clock (30pF + 1TTL Load)

- Fast program time: 1.4ms(typ.) and 5ms(max.)/page (256-byte per page)

- Fast erase time: 60ms(typ.) and 120ms(max.)/sector (4K-byte per sector) ; 1s(typ.) and 2s(max.)/chip(512Kb)

PIN DESCRIPTION

SYMBOL	DESCRIPTION
CS#	Chip Select
SI	Serial Data Input
SO	Serial Data Output
SCLK	Clock Input
HOLD#	Hold, to pause the device without deselecting the device
WP#	Write Protection
VCC	+ 3.3V Power Supply
GND	Ground

FLASH fiscal memory Programmable IC Chips MX25L512MC-12G 512K-BIT [x 1] CMOS SERIAL
