General Description
The LM809/810 microprocessor supervisory circuits can be used to monitor the power supplies in microprocessor and digital systems. They provide a reset to the microprocessor during power-up, power-down and brown-out conditions. The function of the LM809/810 is to monitor the VCC supply voltage, and assert a reset signal whenever this voltage declines below the factory-programmed reset threshold. The reset signal remains asserted for 240ms after VCC rises above the threshold. The LM809 has an active-low RESET output, while the LM810 has an active-high RESET output. Seven standard reset voltage options are available, suitable for monitoring 5V, 3.3V, and 3V supply voltages. With a low supply current of only 15µA, the LM809/810 are ideal for use in portable equipment. The LM809/LM810 are available in the 3-pin SOT23 package and in the 6-Lead LLP package.
Features
Precise monitoring of 3V, 3.3V, and 5V supply voltages
Superior upgrade to MAX809/810 n Fully specified over temperature
140ms min. Power-On Reset pulse width, 240ms typical Active-low RESET Output (LM809) Active-high RESET Output (LM810)
Guaranteed RESET Output valid for VCC≥1V
Low Supply Current, 15µA typ.
Power supply transient immunity
Applications
Microprocessor Systems
Computers n Controllers
Intelligent Instruments
Portable/Battery-Powered Equipment
Automotive
Typical Application Circuit
Connection Diagrams
| Ordering Information | |||||
|---|---|---|---|---|---|
| Reset Threshold (V) | LM809 Supplied as 1000 units, tape & reel | LM809 Supplied as 3000 units, tape & reel | Package Top Mark | Package Type | |
| 4.63 | LM809M3-4.63 | LM809M3X-4.63 | S8B | SOT23-3 | |
| 4.38 | LM809M3-4.38 | LM809M3X-4.38 | S7B | ||
| 4.00 | LM809M3-4.00 | LM809M3X-4.00 | S6B | ||
| 3.08 | LM809M3-3.08 | LM809M3X-3.08 | S5B | ||
| 2.93 | LM809M3-2.93 | LM809M3X-2.93 | S4B | ||
| 2.63 | LM809M3-2.63 | LM809M3X-2.63 | S3B | ||
| 2.45 | LM809M3-2.45 | LM809M3X-2.45 | SFB | ||
| Reset Threshold (V) | LM810 Supplied as 1000 units, tape & reel | LM810 Supplied as 3000 units, tape & reel | Package Top Mark | Package Type | |
| 4.63 | LM810M3-4.63 | LM810M3X-4.63 | SEB | SOT23-3 | |
| 4.38 | LM810M3-4.38 | LM810M3X-4.38 | SDB | ||
| 4.00 | LM810M3-4.00 | LM810M3X-4.00 | SCB | ||
| 3.08 | LM810M3-3.08 | LM810M3X-3.08 | SBB | ||
| 2.93 | LM810M3-2.93 | LM810M3X-2.93 | SAB | ||
| 2.63 | LM810M3-2.63 | LM810M3X-2.63 | S9B | ||
| Reset Threshold (V) | LM809 Supplied as 1000 units, tape & reel | LM809 Supplied as 4500 units, tape & reel | Package Top Mark | Package Type | |
| 2.63 | LM809LD-2.63 | LM809LDX-2.63 | S13 | LLP-6 | |
Pin Descriptions
| PIN | NAME | FUNCTION | |
|---|---|---|---|
| (LLP) | SOT-23 | ||
| 1 | 1 | GND | Ground reference |
| 3 | 2 | RESET (LM809) | Active-low output. RESET remains low while VCC is below the reset threshold, and for 240ms after VCC rises above the reset threshold. |
| RESET (LM810) | Active-high output. RESET remains high while VCC is below the reset threshold, and for 240ms after VCC rises above the reset threshold | ||
| 5 | 3 | VCC | Supply Voltage (+5V, +3.3V, or +3.0V) |
