Product Details:
Payment & Shipping Terms:
|
| VDSS: | −30 V | VDGR: | −30 V |
|---|---|---|---|
| VGSS: | ±20 V | ID: | −11 A |
| PD: | 1.9 W | ||
| Highlight: | power mosfet ic,silicon power transistors |
||
Lithium Ion Battery Applications
Notebook PC Applications
Portable Equipment Applications
• Small footprint due to small and thin package
• Low drain-source ON resistance: RDS (ON) = 8.1 mΩ (typ.)
• High forward transfer admittance: |Yfs| = 23 S (typ.)
• Low leakage current: IDSS = −10 µA (max) (VDS = −30 V)
• Enhancement-mode: Vth = −0.8 to −2.0 V (VDS = −10 V, ID = −1 mA)
Note: For (Note 1), (Note 2), (Note 3) and (Note 4), please refer to the next page. This transistor is an electrostatic sensitive device. Please handle with caution
Maximum Ratings (Ta = 25°C)
| Characteristics | Symbol | Rating | Unit |
| Drain-source voltage | VDSS | −30 | V |
| Drain-gate voltage (RGS = 20 kΩ) | VDGR | −30 | V |
| Gate-source voltage | VGSS | ±20 | V |
| Drain power dissipation (t = 10 s) | PD | 1.9 | W |
| Drain power dissipation (t = 10 s) | PD | 1.0 | W |
| Single pulse avalanche energy | EAS | 31.5 | mJ |
| Avalanche current | IAR | −11 | A |
| Repetitive avalanche energy | EAR | 0.19 | mJ |
| Channel temperature | Tch | 150 | °C |
