►Fully Integrated VCC and Vpp Switching for Single-Slot PC Card Interface

►Low rDS(on) (70-mΩ 5-V VCC Switch and 3.3-V VCC Switch)

►Compatible With Industry-Standard Controllers

►3.3-V Low-Voltage Mode

►Meets PC Card Standards

►12-V Supply Can Be Disabled Except During 12-V Flash Programming

►Short-Circuit and Thermal Protection

►Space-Saving 16-Pin SSOP (DB) and 20-Pin HTSSOP (PWP)

►Compatible With 3.3-V, 5-V, and 12-V PC Cards

►Break-Before-Make Switching

description The TPS2211A PC Card power-interface switch provides an integrated power-management solution for a single PC Card. All of the discrete power MOSFETs, a logic section, current limiting, and thermal protection for PC Card control are combined on a single integrated circuit, using the Texas Instruments LinBiCMOS process. The circuit allows the distribution of 3.3-V, 5-V, and/or 12-V card power, and is compatible with many PCMCIA controllers. The current-limiting feature eliminates the need for fuses, which reduces component count and improves reliability. Current-limit reporting can help the user isolate a system fault to the PC Card. controllers. The current-limiting feature eliminates the need for fuses, which reduces component count and improves reliability. Current-limit reporting can help the user isolate a system fault to the PC Card. The TPS2211A features a 3.3-V low-voltage mode that allows for 3.3-V switching without the need for 5 V. Bias power can be derived from either the 3.3-V or 5-V inputs. This facilitates low-power system designs such as sleep mode and pager mode where only 3.3 V is available.
