DDTC144EE-7-F NPN PRE-BIASED SMALL SIGNAL SOT-523 SURFACE MOUNT TRANSISTOR

: Large Image : DDTC144EE-7-F NPN PRE-BIASED SMALL SIGNAL SOT-523 SURFACE MOUNT TRANSISTOR

Product Details:

Place of Origin:	original factory
Brand Name:	anterwell
Certification:	new & original
Model Number:	DDTC144EE-7-F

Payment & Shipping Terms:

Minimum Order Quantity:	20pcs
Price:	Negotiate
Packaging Details:	Please contact me for details
Payment Terms:	Western Union, T/T, MoneyGram
Supply Ability:	5000pcs

Contact Now

Detailed Product Description

Package:	SOT-523	Peak Dc Collector Current:	100 MA
Power Dissipation:	150 MW	MAX Operating Temperature:	+ 150 °C
Min Operating Min Temperature:	- 55 °C	Factory Packing Quantity:	3000
Highlight:	multi emitter transistor , silicon power transistors

DDTC144EE-7-F NPN PRE-BIASED SMALL SIGNAL SOT-523 SURFACE MOUNT TRANSISTOR

Features

Epitaxial Planar Die Construction

Complementary PNP Types Available (DDTA)

Built-In Biasing Resistors, R1 = R2

Lead Free/RoHS Compliant

Mechanical Data

Case: SOT-523

Case Material: Molded Plastic. UL Flammability Classification Rating 94V-0

Moisture sensitivity: Level 1 per J-STD-020C

Terminal Connections: See Diagram

Terminals: Finish - Solderable per MIL-STD-202, Method 208

Lead Free Plating (Matte Tin Finish annealed over Alloy 42 leadframe).

Marking & Type Code Information: See Table Below and Last Page

Ordering Information: See Last Page

Weight: 0.002 grams (approximate) P/N R1

DDTC144EE-7-F NPN PRE-BIASED SMALL SIGNAL SOT-523 SURFACE MOUNT TRANSISTOR

Maximum Ratings @ TA = 25C unless otherwise specified

Characteristic	Symbol	Value	Unit
Supply Voltage (3) to (2)	VCC	50	V
Input Voltage (1) to (2) DDTC123EE DDTC143EE DDTC114EE DDTC124EE DDTC144EE DDTC115EE	VIN	-10 to +12 -10 to +30 -10 to +40 -10 to +40 -10 to +40 -10 to +40	V
Output Current DDTC123EE DDTC143EE DDTC114EE DDTC124EE DDTC144EE DDTC115EE	IO	100 100 50 30 100 20	mA
Power Dissipation	Pd	150	mW
Thermal Resistance, Junction to Ambient Air (Note 2)	RJA	833	C/W
Operating and Storage and Temperature Range	Tj, TSTG	-55 to +150	°C

Note: 1. No purposefully added lead. 2. Mounted on FR4 PC Board with recommended pad layout at http://www.diodes.com/datasheets/ap02001.pdf.

Electrical Characteristics @ TA = 25C unless otherwise specified

Characteristic		Symbol	Min	Typ	Max	Unit	Test Condition
Input Voltage		Vl(off)	0.5	1.1	---	V	VCC = 5V, IO = 100A
Input Voltage		Vl(on)	---	1.9	3	V	VO = 0.3V, IO = 20mA, DDTC123EE VO = 0.3V, IO = 20mA, DDTC143EE VO = 0.3V, IO = 10mA, DDTC114EE VO = 0.3V, IO = 5mA, DDTC124EE VO = 0.3V, IO = 2mA, DDTC144EE VO = 0.3V, IO = 1mA, DDTC115EE
Output Voltage		VO(on)	---	0.1	0.3	V	IO/Il =10mA/0.5mA, DDTC123EE IO/Il =10mA/0.5mA, DDTC143EE IO/Il =10mA/0.5mA, DDTC114EE IO/Il =10mA/0.5mA, DDTC124EE IO/Il =10mA/0.5mA, DDTC144EE IO/Il =5mA/0.25mA, DDTC115EE
Input Current	DDTC123EE DDTC143EE DDTC114EE DDTC124EE DDTC144EE DDTC115EE	Il	---	---	3.8 1.8 0.88 0.36 0.18 0.15	mA	VI = 5V
Output Current		IO(off)	---	---	0.5	μA	VCC = 50V, VI = 0V
DC Current Gain	DDTC123EE DDTC143EE DDTC114EE DDTC124EE DDTC144EE DDTC115EE	Gl	20 20 30 56 68 82	--	---	---	VO = 5V, IO = 20mA VO = 5V, IO = 10mA VO = 5V, IO = 5mA VO = 5V, IO = 5mA VO = 5V, IO = 5mA VO = 5V, IO = 5mA
Input Resistor (R1) Tolerance		△R1	-30	--	+30	%	--------
Resistance Ratio		R2/R1	0.8	1	1.2	--	--------
Gain-Bandwidth Product*		fT	--	250	---	MHz	VCE = 10V, IE = 5mA, f = 100MHz
