74LCX04MTCX Low Voltage Hex Inverter with 5V Tolerant Inputs amplifier ic chip

: Large Image : 74LCX04MTCX Low Voltage Hex Inverter with 5V Tolerant Inputs amplifier ic chip

Product Details:

Place of Origin:	original factory
Brand Name:	FAIRCHILD
Certification:	new & original
Model Number:	74LCX04MTCX

Payment & Shipping Terms:

Minimum Order Quantity:	10pcs
Price:	Negotiate
Packaging Details:	Please contact me for details
Delivery Time:	1 day
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	20000pcs

Contact Now

Detailed Product Description

Supply Voltage:

-0.5 To +7.0V

DC Input Voltage:

-0.5 To +7.0V

DC Input Diode Current:

- 50 MA

Storage Temperature:

- 65 To+ 150 C

Highlight:

electronic integrated circuit

linear integrated circuits

74LCX04MTCX Low Voltage Hex Inverter with 5V Tolerant Inputs

General Description

The LCX04 contains six inverters. The inputs tolerate voltages up to 7V allowing the interface of 5V systems to 3V systems. The 74LCX04 is fabricated with advanced CMOS technology to achieve high speed operation while maintaining CMOS low power dissipation.

Features
■ 5V tolerant inputs

■ 2.3V–3.6V VCC specifications provided

■ 5.2 ns tPD max (VCC 3.3V), 10 PA ICC max

■ Power down high impedance inputs and outputs

■ r24 mA output drive (VCC 3.0V)

■ Implements patented noise/EMI reduction circuitry

■ Latch-up performance exceeds JEDEC 78 conditions

■ ESD performance: Human body model ! 2000V Machine model ! 200V

■ Leadless Pb-Free DQFN package

Absolute Maximum Ratings

Symbol	Parameter	Value	Conditions	Units
VCC	Supply Voltage	- 0.5 to +7.0		V
VI	DC Input Voltage	- 0.5 to +7.0		V
VO	DC Output Voltage	- 0.5 to VCC +0.5	Output in HIGH or LOW State	V
IIK	DC Input Diode Current	-50	VI <ND	mA
IOK	DC Output Diode Current	-50 +50	VO <GND VO > VCC	mA
IO	DC Output Source/Sink Current	50		mA
ICC	DC Supply Current per Supply Pin	+100		mA
IGND	DC Ground Current per Ground Pin	+100		mA
TSTG	Storage Temperature	-65to+150		C
