TLP124BV Office Machine Programmable Controllers Office Machine Telecommunication common ic chips

: Large Image : TLP124BV Office Machine Programmable Controllers Office Machine Telecommunication common ic chips

Product Details:

Place of Origin:	Original
Brand Name:	TOSHIBA
Certification:	Original Factory Pack
Model Number:	TLP124BV

Payment & Shipping Terms:

Minimum Order Quantity:	50pcs
Price:	negotiation
Packaging Details:	please contact me for details
Delivery Time:	1 day
Payment Terms:	T/T, Western Union,PayPal
Supply Ability:	5200PCS

Contact Now

Detailed Product Description

Tstg:	−55~125 °C	Topr:	−55~100 °C
Tsol:	260 °C	PT:	200 MW
ΔPT / °C:	−2.0mW / °C	BVS:	3750 Vrms
Highlight:	integrated circuit ic , integrated circuit components

TLP124BV Office Machine Programmable Controllers Office Machine Telecommunication

TLP124BV Office Machine Programmable Controllers Office Machine Telecommunication common ic chips

The TOSHIBA mini flat coupler TLP124 is a small outline coupler, suitable for surface mount assembly.
TLP124 consists of a photo transistor optically coupled to a gallium arsenide infrared emitting diode.

• Collector−emitter voltage: 80 V min.
• Current transfer ratio: 100% min.
Rank BV: 200% min.
• Isolation voltage: 3750Vrms min.
• UL recognized: UL1577, file No. E67349

Current Transfer Ratio

Classification	Ta = 25°C IF = 1mA VCE = 0.5V	Ta = 25°C F = 0.5mA VCE = 1.5V	Ta = −25~75°C IF = 1mA VCE = 0.5V	Marking Of Classification
Rank BV	200%	100%	100%	BV
Standard	100%	50%	50%	BV, Blank

(Note) Application type name for certification test, please use standard product type name, i. e. TLP124 (BV): TLP124

Absolute Maximum Ratings (Ta = 25°C)

Characteristic	Symbol	Rating	Unit
LED
Forward current	IF	50	mA
Forward current derating	ΔIF / °C	−0.7 (Ta ≥ 53°C)	mA / °C
Peak forward current (100μs pulse, 100pps)	IFP	1	A
Reverse voltage	VR	5	V
Junction temperature	Tj	125	°C
Detector
Collector−emitter voltage	VCEO	80	V
Emitter−collector voltage	VECO	7	V
Collector current	IC	50	mA
Peak collector current (10ms pulse, 100pps)	ICP	100	mA
Power dissipation	PC	150	mW
Power dissipation derating (Ta ≥ 25°C)	ΔPC / °C	−1.5	mA / °C
Junction temperature	Tj	125	°C
Storage temperature range	Tstg	−55~125	°C
Operating temperature range	Topr	−55~100	°C
Lead soldering temperature (10s)	Tsol	260	°C
Total package power dissipation	PT	200	mW
Total package power dissipation derating (Ta ≥ 25°C)	ΔPT / °C	−2.0	mW / °C
Isolation voltage (AC, 1min., R.H. ≤ 60%) (Note 1)	BVS	3750	Vrms

TLP124BV Office Machine Programmable Controllers Office Machine Telecommunication common ic chips
