Product Details:
Payment & Shipping Terms:
|
| IF(AV): | 3.0 A | VRRM: | 50 V, 60 V |
|---|---|---|---|
| IFSM: | 60 A | VF At IF = 3.0 A: | 0.51 V |
| Highlight: | bridge rectifier circuit,signal schottky diode |
||
FEATURES
• Low profile package
• Ideal for automated placement
• Guardring for overvoltage protection
• Low power losses, high efficiency
• Low forward voltage drop
• High surge capability
• Meets MSL level 1, per J-STD-020, LF maximum peak of 260 °C
• Compliant to RoHS directive 2002/95/EC and in accordance to WEEE 2002/96/EC
TYPICAL APPLICATIONS
For use in low voltage, high frequency inverters, freewheeling, dc-to-dc converters, and polarity protection applications.
MECHANICAL DATA
Case: DO-214AA (SMB) Molding compound meets UL 94 V-0 flammability rating Base P/N-E3 - RoHS compliant, commercial grade Terminals: Matte tin plated leads, solderable per J-STD-002 and JESD 22-B102 E3 suffix meets JESD 201 class 1A whisker test Polarity: Color band denotes the cathode end
| PRIMARY CHARACTERISTICS | |
| IF(AV) | 3.0 A |
| VRRM | 50 V, 60 V |
| IFSM | 60 A |
| VF at IF = 3.0 A | 0.51 V |
| TJ max. | 150 °C |
| MAXIMUM RATINGS (TA = 25 °C unless otherwise noted) | ||||
| PARAMETER | SYMBOL | B350B | B360B | UNIT |
| Device marking code | B35 | B36 | ||
| Maximum repetitive peak reverse voltage | VRRM | 50 | 60 | V |
| Maximum average forward rectified current at TL (fig. 1) | IF(AV) | 3.0 | A | |
| Peak forward surge current 8.3 ms single half sine-wave superimposed on rated load | IFSM | 60 | A | |
| Operating junction and storage temperature range | TJ, TSTG | - 55 to + 150 | °C | |
RATINGS AND CHARACTERISTICS CURVES
(TA = 25 °C unless otherwise noted)
