TLP621-2 PROGRAMMABLE CONTROLLER AC/DC-INPUT MODULE SOLID STATE RELAY

: Large Image : TLP621-2 PROGRAMMABLE CONTROLLER AC/DC-INPUT MODULE SOLID STATE RELAY

Product Details:

Place of Origin:	original factory
Brand Name:	TOSHIBA
Certification:	new & original
Model Number:	TLP621-2

Payment & Shipping Terms:

Minimum Order Quantity:	20pcs
Price:	Negotiate
Packaging Details:	Please contact me for details
Delivery Time:	1 day
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	9500pcs

Contact Now

Detailed Product Description

Storage Temperature Range:

−55~125 °C

Operating Temperature Range:

−55~100 °C

Lead Soldering Temperature:

260 (10 S) °C

Isolation Voltage:

5000 (AC, 1min., R.H.≤ 60%) Vrms

Highlight:

electronic integrated circuit

linear integrated circuits

TLP621-2 PROGRAMMABLE CONTROLLER AC/DC-INPUT MODULE SOLID STATE RELAY

TLP621-2 PROGRAMMABLE CONTROLLER AC/DC-INPUT MODULE SOLID STATE RELAY

The TOSHIBA TLP621, −2 and −4 consists of a photo−transistor
optically coupled to a gallium arsenide infrared emitting diode. The
TLP621−2 offers two isolated channels in an eight lead plastic DIP,
which the TLP621−4 provides four isolated channels in a sixteen plastic DIP.

• Collector−emitter voltage: 55 V (min.)
• Current transfer ratio: 50% (min.) Rank GB: 100% (min.)

Absolute Maximum Ratings (Ta = 25°C)

Characteristic		Symbol	Rating		Unit
Characteristic		Symbol	TLP621	TLP621−2 TLP621−4	Unit
L E D	Forward current	IF	60	50	mA
	Forward current derating	ΔIF /°C	−0.7 (Ta > 39°C)	−0.5 (Ta = 25°C)	mA /°C
	Pulse forward current	IFP	1 (100μs pulse, 100pps)		A
	Power dissipation	PD	100	70	mW
	Power dissipation derating	ΔPD /°C	−1.0	−0.7	mW /°C
	Reverse voltage	VR	5		V
	Junction temperature	Tj	125		°C
D e t e c t o r	Collector−emitter voltage	VCEO	55		V
	Emitter−collector voltage	VECO	V		V
	Collector current	IC	50		mA
	Collector power dissipation (1 circuit)	PC	150	100	mW
	Collector power dissipation derating (1 circuit, Ta ≥ 25°C)	ΔPC /°C	−1.5	−1.0	mW /°C
	Junction temperature	Tj	125		°C
Storage temperature range		Tstg	−55~125		°C
Operating temperature range		Topr	−55~100		°C
Lead soldering temperature		Tsol	260 (10 s)		°C
Total package power dissipation		PT	250	150	mW
Total package power dissipation derating (Ta ≥ 25°C)		ΔPT /°C	−2.5	−1.5	mW /°C
Isolation voltage (Note 1)		BVS	5000 (AC, 1min., R.H.≤ 60%)		Vrms

Note: Using continuously under heavy loads (e.g. the application of high temperature/current/voltage
and the significant change in temperature, etc.) may cause this product to decrease in the relia
-bility significantly even if the operating conditions (i.e. operating temperature/current/voltage,
     etc.) are within the absolute maximum ratings. Please design the appropriate reliability upon
     reviewing the Toshiba Semiconductor Reliability Handbook (“Handling Precautions”/“Derating
     Concept and Methods”) and individual reliability data (i.e. reliability test report and estimated failure rate, etc).
(Note 1) Device considered a two terminal: LED side pins shorted together, and detector side pins shorted together.

Recommended Operating Conditions

Characteristic	Symbol	Min.	Typ.	Max.	Unit
Supply voltage	VCC	―	5	24	V
Forward current	IF	―	16	20	mA
Collector current	IC	―	1	10	mA
Operating temperature	Topr	−25	―	85	°C

Note: Recommended operating conditions are given as a design guideline to
     obtain expected performance of the device. Additionally, each item is an
     independent guideline respectively. In developing designs using this pro
   -duct, please confirm specified characteristics shown in this document.
