Common Integrated Circuits L298N Circuit Dual Full Bridge Driver
DUAL FULL-BRIDGE DRIVER
. OPERATING SUPPLY VOLTAGE UP TO 46 V
. TOTAL DC CURRENT UP TO 4 A
. LOW SATURATION VOLTAGE
. OVERTEMPERATURE PROTECTION
. LOGICAL ”0” INPUT VOLTAGE UP TO 1.5 V
(HIGH NOISE IMMUNITY)
DESCRIPTION
The L298 is an integrated monolithic circuit in a 15- lead Multiwatt and PowerSO20 packages. It is a high voltage, high current dual full-bridge driver designedto acceptstandardTTL logic levels anddrive inductive loads such as relays, solenoids, DC and steppingmotors. Two enableinputs are providedto enableor disablethe deviceindependentlyof theinput signals. The emitters of the lower transistors of each bridge are connected togetherand the correspondingexternalterminal can be used for the connectionofanexternalsensingresistor.Anadditional supplyinput is provided so that the logic works at a lower voltage.
BLOCK DIAGRAM
PIN CONNECTIONS (top view)
ABSOLUTE MAXIMUM RATINGS
| Symbol | Parameter | Value | Unit |
| VS | Power Supply | 50 | V |
| VSS | Logic Supply Voltage | 7 | V |
| VI,Ven | Input and Enable Voltage | –0.3 to 7 | V |
| IO |
Peak Output Current (each Channel) – Non Repetitive (t = 100µs) –Repetitive (80% on –20% off; ton = 10ms) –DC Operation |
3 2.5 2 |
A A A |
| Vsens | Sensing Voltage | –1 to 2.3 | V |
| Ptot | Total Power Dissipation (Tcase = 75°C) | 25 | W |
| Top | Junction Operating Temperature | –25 to 130 | °C |
