SST25VF064C-80-4I-Q2AE-T 64 Mbit SPI Serial Dual I/O Flash

FEATURES:

• Single Voltage Read and Write Operations – 2.7-3.6V

• Serial Interface Architecture

– SPI Compatible: Mode 0 and Mode 3

• Dual Input/Output Support

– Fast-Read Dual-Output Instruction

– Fast-Read Dual I/O Instruction

• High Speed Clock Frequency

– 80 MHz for High-Speed Read (0BH)

– 75 MHz for Fast-Read Dual-Output (3BH)

– 50 MHz for Fast-Read Dual I/O (BBH)

– 33 MHz for Read Instruction (03H)

• Superior Reliability

– Endurance: 100,000 Cycles (typical)

– Greater than 100 years Data Retention

• Low Power Consumption

– Active Read Current: 12 mA (typical @ 80 MHz) for single-bit read)

– Active Read Current: 14 mA (typical @ 75MHz) for dual-bit rea

d)

– Standby Current: 5 µA (typical)

• Flexible Erase Capability

– Uniform 4 KByte sectors

– Uniform 32 KByte overlay blocks

– Uniform 64 KByte overlay blocks

• Fast Erase – Chip-Erase Time: 35 ms (typical)

– Sector-/Block-Erase Time: 18 ms (typical)

• Page-Program – 256 Bytes per page

– Single and Dual Input support

– Fast Page-Program time in 1.5 ms (typical)

• End-of-Write Detection

– Software polling the BUSY bit in Status Register

• Write Protection (WP#)

– Enables/Disables the Lock-Down function of the status register

• Software Write Protection

– Write protection through Block-Protection bits in status register

• Security ID

– One-Time Programmable (OTP) 256 bit, Secure ID

- 64 bit Unique, Factory Pre-Programmed identifier
