FOD817C Integrated Circuit Chip 4 - Pin Phototransistor Optocouplers

FOD814 Series, FOD617 Series, FOD817 Series

4-Pin Phototransistor Optocouplers

Features

■ AC input response (FOD814 only)

■ Applicable to Pb-free IR reflow soldering

■ Compact 4-pin package

■ Current transfer ratio in selected groups:

FOD617A: 40–80% FOD817: 50–600%

FOD617B: 63–125% FOD817A:80–160%

FOD617C:100–200% FOD817B: 130–260%

FOD617D:160–320% FOD817C:200–400%

FOD814: 20–300% FOD817D:300–600%

FOD814A: 50–150%

■ C-UL, UL and VDE approved

■ High input-output isolation voltage of 5000Vrms

■ Higher operating temperatures (versus FODXXX counterparts)

■ Minimum BVCEO of 70V guaranteed

Applications

FOD814 Series

■ AC line monitor

■ Unknown polarity DC sensor

■ Telephone line interface FOD617 and FOD817 Series

■ Power supply regulators

■ Digital logic inputs

■ Microprocessor inputs

Typical Electrical/Optical Characteristic Curves (TA = 25°C Unless otherwise specified.)
