Product Details:
Payment & Shipping Terms:
|
| Case:: | Molded Glass DO-41G / Molded Plastic DO-41 | Epoxy:: | UL 94V-O Rate Flame Retardant |
|---|---|---|---|
| Terminals: | Axial Leads, Solderable Per MIL-STD-202 | Polarity:: | Color Band Denotes Positive End |
| Weight:: | 0.012 Ounce, 0.3 Gram | ||
| Highlight: | bridge rectifier circuit,signal schottky diode |
||
1N4728A~1N4764A
GLASS PASSIVATED JUNCTION SILICON ZENER DIODE
FEATURES
• Low profile package
• Built-in strain relief
• Low inductance
• High temperature soldering : 260°C /10 seconds at terminals
• Plastic package has Underwriters Laboratory Flammability Classification 94V-O
• Both normal and Pb free product are available :
Normal : 80~95% Sn, 5~20% Pb
Pb free: 98.5% Sn above
MECHANICAL DATA
• Case: Molded Glass DO-41G / Molded plastic DO-41
• Epoxy:UL 94V-O rate flame retardant
• Terminals: Axial leads, solderable per MIL-STD-202,
• Method 208 guaranteed • Polarity: Color band denotes positive end
• Mounting position:Any
• Weight: 0.012 ounce, 0.3 gram
• Ordering information : Suffix : “ -G ” to order Molded Glass Package Suffix : “ -P ” to order Molded plastic Package
• Packing information B - 1K per Bulk box T/R - 5K per 13" paper Reel T/B - 2.5K per horiz. tape & Ammo box
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25°C ambient temperature unless otherwise specified.
| Parameter | symbol | Value | unit |
| PowerD issipation atTam b = 25 O C | PTO T | 1 | 1 W * |
| Junction Tem perature | TJ | 150 | O C |
| Storage Tem perature Range | TSTG | -55 to + 150 | O C |
