Surface Mount Zero Bias Schottky HSMS2822 Rectifier Diode Bridge Rectifier Circuit

Description                                                                                                    Pin Connection

This specific line of Schottky diodes were specifically

designed for both digital and analog applications. This

series includes a wide range of specifications and

package configurations which gives the designer wide

flexibility. General applications of these Schottky diodes

are clamping, mixing, detecting, sampling, switching,

and wave shaping. The B822x series of diodes is the best

general all-purpose diode for most applications,

featuring low series resistance, low forward voltage at

all current levels and desired RF characteristics.

At Bay Linear, our commitment to quality components

gives our customers a reliable source of RF products,

which are tested at a more stringent level than our

competitors. Manufacturing techniques assure that when

two diodes are mounted into a single package they are

taken from adjacent sites on the wafer. In cross

referenced parts, we guarantee pin to pin compatibility.

The various package configurations available provide a

low cost solution to a wide variety of design problems.

Features

• Low FIT (Failure in Time) Rate*

• Low Turn-On Voltage (As Low as 0.34 V at 1

  mA)

• Six-sigma Quality Level

• Single, Dual and Quad Versions

• Unique Configurations in Surface Mount

  SOT-23/143 Package

• B-282K Grounded Center Leads Provide up to

  10 dB Higher Isolation

• Matched Diodes for Consistent Performance

• High Thermal Conductivity for greater Power
