SPM6530 Step down Regulator comprising of Controller IC Synchronous DC-DC and Power MOSFET

: Large Image : SPM6530 Step down Regulator comprising of Controller IC Synchronous DC-DC and Power MOSFET

Product Details:

Place of Origin:	Original
Brand Name:	EXAR
Certification:	Original
Model Number:	SPM6530

Payment & Shipping Terms:

Minimum Order Quantity:	5 PCS
Price:	0.1USD
Packaging Details:	contact us for more details
Delivery Time:	1 day
Payment Terms:	T/T, Western Union,Paypal
Supply Ability:	10000PCS/DAY

Contact Now

Detailed Product Description

Features:	High-Speed Response DC-DC Step Down RegulatorCircuit	Voltage:	0.75 V To 5.5 V
Temperature:	No	Application:	High Current Distributed Power Systems
Description:	A Synchronous DC-DC Step DownRegulator	Type:	Controller IC
Highlight:	soldering smd resistor , resistors transistors capacitors

SPM6530 Step down Regulator comprising of Controller IC

VIN = 4.5 V to 30 V, 10 A

Synchronous DC-DC Step down Regulator

comprising of Controller IC and Power MOSFET

FEATURES

High-Speed Response DC-DC Step Down Regulator

Circuit that employs Hysteretic Control System SPM6530 Step down Regulator comprising of Controller IC Synchronous DC-DC and Power MOSFET

Two 11 mΩ (Typ.)

MOSFETs for High Efficiency at 10 A

SKIP (discontinuous) Mode for Light Load Efficiency

Up to 10 A Output Current

Input VoltageRange : AVIN : 4.5 V to 30 V,

PVIN : 4.5 V to 30 V,

Output Voltage Range : 0.75 V to 5.5 V

Selectable Switching Frequency 250 kHz , 750 kHz ,

1250 kHz

Adjustable Soft Start

Low Operating and Standby Quiescent Current

Open Drain Power Good Indication for Output Over ,

Under Voltage

Built-in Under Voltage Lockout (UVLO),

Thermal Shut Down (TSD),

Over Voltage Detection (OVD),

Under Voltage Detection (UVD),

Over Current Protection (OCP),

Short Circuit Protection (SCP)

HQFN040-A3-0606B ( Size : 6 mm X 6 mm, 0.5 mm

pitch ), 40pin Plastic Quad Flat Non-leaded Package

Heat Slug Down (QFN Type)

DESCRIPTION

NN30312A is a synchronous DC-DC Step down

Regulator (1-ch) comprising of a Controller IC and two

power MOSFETs and employs the hysteretic control

system.

By this system, when load current changes suddenly, it

responds at high speed and minimizes the changes of

output voltage.

Since it is possible to use capacitors with small

capacitance and it is unnecessary to add external parts

for system phase compensation, this IC realizes

downsizing of set and reducing in the number of external

parts. Output voltage is adjustable by user.

Maximum current is 10 A.

APPLICATIONS

High Current Distributed Power Systems such as

・HDDs (Hard Disk Drives)

・SSDs (Solid State Drives)

・PCs

・Game consoles

・Servers

・Security Cameras

・Network TVs

・Home Appliances

・OA Equipment etc.

VOUT [V]	RFB1 [Ω]	RFB2 [Ω]
5.0	11.0 k	1.5 k
3.3	4.5 k	1.0 k
1.8	2.0 k	1.0 k
1.0	1.0 k	1.5 k
