Product Details:
Payment & Shipping Terms:
|
| I/O Supply Voltage Relative To GND: | –0.5 To +4.0 V | JTAG I/O Supply Voltage Relative To GND: | –0.5 To +4.0 V |
|---|---|---|---|
| Storage Temperature (ambient): | –65 To +150 °C | Junction Temperature: | +125 °C |
| Industrial Temperature: | –40°C To +85°C | XCF01S/XCF02S/XCF04S Supply Voltage: | 3.3V |
| Highlight: | programming ic chips,programmable audio chip |
||
Platform Flash In-System Programmable Configuration PROMS
Features
• In-System Programmable PROMs for Configuration of Xilinx FPGAs
• Low-Power Advanced CMOS NOR FLASH Process
• Endurance of 20,000 Program/Erase Cycles
• Operation over Full Industrial Temperature Range (–40°C to +85°C)
• IEEE Standard 1149.1/1532 Boundary-Scan (JTAG) Support for Programming, Prototyping, and Testing
• JTAG Command Initiation of Standard FPGA Configuration
• Cascadable for Storing Longer or Multiple Bitstreams
• Dedicated Boundary-Scan (JTAG) I/O Power Supply (VCCJ)
• I/O Pins Compatible with Voltage Levels Ranging From 1.5V to 3.3V
• Design Support Using the Xilinx Alliance ISE and Foundation ISE Series Software Packages
• XCF01S/XCF02S/XCF04S
♦ 3.3V supply voltage
♦ Serial FPGA configuration interface (up to 33 MHz)
♦ Available in small-footprint VO20 and VOG20 packages.
• XCF08P/XCF16P/XCF32P
♦ 1.8V supply voltage
♦ Serial or parallel FPGA configuration interface (up to 33 MHz)
♦ Available in small-footprint VO48, VOG48, FS48, and FSG48 packages
♦ Design revision technology enables storing and accessing multiple design revisions for configuration
♦ Built-in data decompressor compatible with Xilinx advanced compression technology
Description
Xilinx introduces the Platform Flash series of in-system programmable configuration PROMs. Available in 1 to 32 Megabit (Mbit) densities, these PROMs provide an easy-to-use, cost-effective, and reprogrammable method for storing large Xilinx FPGA configuration bitstreams. The Platform Flash PROM series includes both the 3.3V XCFxxS PROM and the 1.8V XCFxxP PROM. The XCFxxS version includes 4-Mbit, 2-Mbit, and 1-Mbit PROMs that support Master Serial and Slave Serial FPGA configuration modes (Figure 1). The XCFxxP version includes 32-Mbit, 16-Mbit, and 8-Mbit PROMs that support Master Serial, Slave Serial, Master SelectMAP, and Slave SelectMAP FPGA configuration modes (Figure 2).
Figure 1: XCFxxS Platform Flash PROM Block Diagram
Figure 2: XCFxxP Platform Flash PROM Block Diagram
Absolute Maximum Ratings
| Symbol | Description | XCF01S, XCF02S, XCF04S | XCF08P, XCF16P, XCF32P | Units | |
| VCCINT | Internal supply voltage relative to GND | –0.5 to +4.0 | –0.5 to +2.7 | V | |
| VCCO | I/O supply voltage relative to GND | –0.5 to +4.0 | –0.5 to +4.0 | V | |
| VCCJ | JTAG I/O supply voltage relative to GND | –0.5 to +4.0 | –0.5 to +4.0 | V | |
| VIN | Input voltage with respect to GND | VCCO < 2.5V | –0.5 to +3.6 | –0.5 to +3.6 | V |
| VCCO ≥ 2.5V | –0.5 to +5.5 | –0.5 to +3.6 | V | ||
| VTS | Voltage applied to High-Z output | VCCO < 2.5V | –0.5 to +3.6 | –0.5 to +3.6 | V |
| VCCO ≥ 2.5V | –0.5 to +5.5 | –0.5 to +3.6 | V | ||
| TSTG | Storage temperature (ambient) | –65 to +150 | –65 to +150 | °C | |
| TJ | Junction temperature | +125 | +125 | °C | |
Notes:
