3329H-1-103LF Resistance 3329 - 1/4 Round Trimming Potentiometer

: Large Image : 3329H-1-103LF Resistance 3329 - 1/4 Round Trimming Potentiometer

Product Details:

Place of Origin:	Original
Brand Name:	ALLEGRO
Certification:	Original
Model Number:	ACS712TELC-05B

Payment & Shipping Terms:

Minimum Order Quantity:	5 PCS
Price:	0.1USD
Packaging Details:	contact us for more details
Delivery Time:	1 day
Payment Terms:	T/T, Western Union,Paypal
Supply Ability:	10000PCS/DAY

Contact Now

Detailed Product Description

Features:	5 Standard Terminal Styles	Electrical Characteristics:	Standard Resistance
Package:	Original Sealed	Absolute Minimum Resistance:	1 % Or 2 Ohms
Contact Resistance Variation:	3.0 % Or 3 Ohms Max	Type:	Resistance
Highlight:	temperature sensor ic , hall effect sensor ic

3329H-1-103LF Resistance

Features

1.1/4” Round / Single-Turn / Cermet 2.Industrial / Sealed 3.5 standard terminal styles 4.Tape and reel packaging available

5.High-Rel MIL-PRF-39035 6.RoHS compliant* version available

Electrical Characteristics

Standard Resistance Range...................................10 to 1 megohm (see standard resistance table)

Resistance Tolerance ............±10 % std. (closer tolerance available)

Absolute Minimum Resistance......................................1 % or 2 ohms (whichever is greater)

Contact Resistance Variation..........................3.0 % or 3 ohms max. (whichever is greater)

Adjustability

Voltage ....................................±0.05 % Resistance ..............................±0.15 % Resolution.....................................Infinite

Insulation Resistance ................500 vdc. 1,000 megohms min. Dielectric Strength

Sea Level .................................600 vac 80,000 Feet ..............................250 vac Adjustment Angle ..................240 ° nom.

Environmental Characteristics Power Rating @ 85 °C (300 volts max.).................................................0.5 watt

Power Rating @ 150 °C.................0 watt Temperature Range ....-55 °C to +150 °C Temperature Coefficient ....±100 ppm/°C

Seal Test........................85 °C Fluorinert Humidity........MIL-STD-202 Method 106 96 hours(3 % ∆TR,10 Megohms IR)

Vibration.........30 G (1 % ∆TR; 1 % ∆VR) except “P” pin style Shock...........100 G (1 % ∆TR; 1 % ∆VR)

Load Life..............1,000 hours 0.5 watt @ 85 °C (3 % ∆TR; 3 % CRV) Rotational Life ........................200 cycles (4 % ∆TR; 4 % CRV)

Physical Characteristics

Mechanical Angle ..................260 ° nom. Torque .............................5.0 oz-in. max. Stop Strength ..................5.0 oz -in. min.

Terminals ........................Solderable pins Weight ........................................0.02 oz. Marking .........Manufacturer’s trademark,

resistance code, date code,manufacturer’s model number and style Wiper................50 % (Actual TR) ±10 %

Standard Packaging .....50 pcs. per tube Adjustment Tool ..............................H-90

Resistance (Ohms)	Resistance Code
10 20 50	100 200 500
100 200 500 1,000 2,000 5,000 10,000 20,000 25,000 50,000 100,000	101 201 501 102 202 502 103 203 253 503 104
200,000 250,000 500,000 1,000,000	204 254 504 105
