AQY282SX Circuit Board Chips GU ( General Use ) Type [1, 2-Channel ( Form A) 4, 8-Pin Type ] Amusement

: Large Image : AQY282SX Circuit Board Chips GU ( General Use ) Type [1, 2-Channel ( Form A) 4, 8-Pin Type ] Amusement

Product Details:

Place of Origin:	Original
Brand Name:	PANASONIC
Certification:	Original
Model Number:	AQY282SX

Payment & Shipping Terms:

Minimum Order Quantity:	5 PCS
Price:	0.1USD
Packaging Details:	contact us for more details
Delivery Time:	1 day
Payment Terms:	T/T, Western Union,Paypal
Supply Ability:	10000PCS/DAY

Contact Now

Detailed Product Description

Voltage:	350V	Various Package Design:	DIP4,SOP4, DIP8, SOP8
FEATURES:	Low Cost Type	Type:	IC CHIP
Applications:	Telephone Equipment	Load Curren:	500 MA
Highlight:	circuit board ic , electronic components ic

AQY282SX IC CHIP GU (General Use) Type

FEATURES

1. Low cost type. 2. High sensitivity, Low ON resistance Can control a maximum 0.5A (AQY282S,AQW282S) load current with a 5mA input current.

Low ON resistance of 2.5Ω (AQY282S,AQW282S). Stable operation because there are no metallic contact parts.

3. Various package design (DIP4,SOP4, DIP8, SOP8 packages are available) 4. Low-level off state leakage current The SSR has an off state leakage current of several milliamperes, where as the PhotoMOS relay has only 100pA even with the rated load voltage of 350V (AQY280S, AQW280S)

TYPICAL APPLICATIONS

• Modem • Telephone equipment • Security equipment • Sensors • Amusement

Type	Output rating*		Part No.		Packing quantity in tape and reel
Type	Load voltage	Load current	Picked from the 1/2-pin side	Picked from the 3/4-pin side	Packing quantity in tape and reel
AC/DC type	60 V	500 mA	AQY282SX	AQY282SZ	1,000 pcs
	350 V	120 mA	AQY280SX	AQY280SZ
	400 V	100 mA	AQY284SX	AQY284SZ
