MC14512BDR2G Circuit Board Chip Electronics Components 8− Channel Data Selector

: Large Image : MC14512BDR2G Circuit Board Chip Electronics Components 8− Channel Data Selector

Product Details:

Place of Origin:	Malaysia
Brand Name:	ON
Certification:	Original Factory Pack
Model Number:	MC14512BDR2G

Payment & Shipping Terms:

Minimum Order Quantity:	100pcs
Price:	Negotiation
Packaging Details:	in well pack
Delivery Time:	1 Day
Payment Terms:	T/T, Western Union,Paypal
Supply Ability:	30000PCS

Contact Now

Detailed Product Description

Payment:	T/T, PayPal	Package:	SOP-16
Voltage:	−0.5 To +18.0V	Shipment:	FEDEX, DHL,EMS,TNT
Storage Temperature Range:	-65°C To +150°C	Ambient Temperature Range:	-55°C To +125°C
Highlight:	electronic chip board , electronic components ic

MC14512BDR2G

8−Channel Data Selector

8−Channel Data Selector The MC14512B is an 8−channel data selector constructed with MOS P−channel and N−channel enhancement mode devices in a single monolithic structure. This data selector finds primary application in signal multiplexing functions. It may also be used for data routing, digital signal switching, signal gating, and number sequence generation.

Features

• Diode Protection on All Inputs

• Single Supply Operation

• 3−State Output (Logic “1”, Logic “0”, High Impedance)

• Supply Voltage Range = 3.0 Vdc to 18 Vdc • Capable of Driving Two Low−power TTL Loads or One Low−power Schottky TTL Load Over the Rated Temperature Range

• Pb−Free Packages are Available*

MAXIMUM RATINGS (Voltages Referenced to VSS)

Parameter	Symbol	Value	Unit
DC Supply Voltage Range	VDD	−0.5 to +18.0	V
Input or Output Voltage Range	Vin, Vout	−0.5 to VDD + 0.5	V
Input or Output Current (DC or Transient) per Pin	Iin, Iout	±10	mA
Power Dissipation, Per Package	PD	500	mW
Ambient Temperature Range	TA	−55 to +125	°C
Storage Temperature Range	Tstg	−65 to +150	°C
Lead Temperature	TL	260	°C
