Product Details:
Payment & Shipping Terms:
|
| Output Voltage: | 50 V | Input Voltage: | 30 V |
|---|---|---|---|
| Collector Current - Continuous: | 500 MA | Base Current - Continuous: | 25 MA |
| Storage Temperature Range: | -55 To +150 °C | ||
| Highlight: | ic programmer circuit,programmable audio chip |
||
The seven NPN Darlington connected transistors in these arrays are well suited for driving lamps, relays, or printer hammers in a variety of industrial and consumer applications. Their high breakdown voltage and internal suppression diodes insure freedom from problems associated with inductive loads. Peak inrush currents to 500 mA permit them to drive incandescent lamps.
The ULx2003A with a 2.7 k series input resistor is well suited for systems utilizing a 5.0 V TTL or CMOS Logic.
MAXIMUM RATINGS
(TA = 25°C, and rating apply to any one device in the package, unless otherwise noted.)
| Rating | Symbol | Value | Unit |
| Output Voltage | VO | 50 | V |
| Input Voltage | VI | 30 | V |
| Collector Current - Continuous | IC | 500 | mA |
| Base Current - Continuous | IB | 25 | mA |
|
Operating Ambient Temperature Range ULN2003A ULQ2003A |
TA |
-20 to +85 -40 to +85 |
°C |
| Storage Temperature Range | Tstg | -55 to +150 | °C |
| Junction Temperature | TJ | 150 | °C |
|
Thermal Resistance, Junction-to-Ambient Case 751B, D Suffix |
RJA | 100 | °C/W |
|
Thermal Resistance, Junction-to-Case Case 751B, D Suffix |
RJC | 20 | °C/W |
|
Electrostatic Discharge Sensitivity (ESD) Human Body Model (HBM) Machine Model (MM) Charged Device Model (CDM) |
ESD |
2000 400 1500 |
V |
TYPICAL PERFORMANCE CURVES - TA = 25°C
