CNY74-2/CNY74-4
Multichannel Optocoupler with Phototransistor Output
Description
The CNY74-2 and CNY74-4 consist of a phototransistor optically coupled to a gallium arsenide infrared emitting diode in a 8 lead, resp. 16 lead plastic dual inline packages. The elements are mounted on one leadframe in coplanar technique, providing a fixed distance between input and output for highest safety requirements.
Applications
Galvanically separated circuits, non-interacting switches.
Features
Absolute Maximum Ratings
for single coupled system
Input (Emitter)
| Parameters | Test Conditions | Symbol | Value | Unit |
| Reserve voltage | VR | 6 | V | |
| Forward current | IF | 60 | mA | |
| Forward surge current | tp ≤ 10 s | IFSM | 1.5 | A |
| Power dissipation | Tamb ≤ 25°C | PV | 100 | mW |
| Junction temperature | Tj | 125 | °C |
Output (Detector)
| Parameters | Test Conditions | Symbol | Value | Unit |
| Collector emitter voltage | VCEO | 70 | V | |
| Emitter collector voltage | VECO | 7 | V | |
| Collector current | IC | 50 | mA | |
| Peak collector current | tp/T = 0.5, tp ≤ 10 ms | ICM | 100 | mA |
| Power dissipation | Tamb ≤ 25°C | PV | 150 | mW |
| Junction temperature | Tj | 125 | °C |
Coupler
| Parameters | Test Conditions | Symbol | Value | Unit |
| DC Isolation test voltage | VIO 1) | 2.5 | V | |
| Total power dissipation | Tamb ≤ 25°C | Ptot | 250 | mW |
| Ambient temperature range | Tamb | –40 to +100 | °C | |
| Storage temperature range | Tstg | –55 to +125 | °C | |
| Soldering temperature | 2 mm from case, t ≤ 10 s | Tsd | 260 | °C |
1) related to standard climate 23/50 DIN 50 014
Pin Connections
