Dual precision monostable multivibrator HEF4538B MSI

DESCRIPTION

The HEF4538B is a dual retriggerable-resettable monostable multivibrator. Each multivibrator has an active LOW trigger/retrigger input (I0), an active HIGH trigger/retrigger input (I1), an overriding active LOW direct reset input (CD), an output (O) and its complement (O), and two pins (CTC, (1) RCTC) for connecting the external timing components Ct and Rt. Typical pulse width variation over temperature range is ± 0,2%.

The HEF4538B may be triggered by either the positive or the negative edges of the input pulse and will produce an accurate output pulse with a pulse width range of 10 µs to infinity. The duration and accuracy of the output pulse are determined by the external timing components Ct and Rt. The output pulse width (T) is equal to Rt × Ct. The linear design techniques in LOCMOS guarantee precise control of the output pulse width.

A LOW level at CD terminates the output pulse immediately. Schmitt-trigger action in the trigger inputs makes the circuit highly tolerant to slower rise and fall times.

HEF4538BP(N): 16-lead DIL; plastic (SOT38-1)

HEF4538BD(F): 16-lead DIL; ceramic (cerdip) (SOT74)

HEF4538BT(D): 16-lead SO; plastic (SOT109-1)

( ): Package Designator North America

         Fig.1 Functional diagram.

    Fig.2 Pinning diagram.

PINNING

I_0A, I_0B input (HIGH to LOW triggered)

I_1A, I_1B input (LOW to HIGH triggered)

C_DA, C_DB direct reset input (active LOW)

O_A, O_B output

O_A, O_B complementary output (active LOW)

C_{TC A}, C_{TC B} external capacitor connections⁽¹⁾

RC_{TC A}, RC_{TC B} external capacitor/ resistor connections

Note 1. Always connected to ground.

Fig.3 Logic diagram.
