Product Details:
Payment & Shipping Terms:
|
| Supply Voltage Relative To GND: | –0.5 To 4.0 V | Input Voltage Relative To GND(1): | –0.5 To 5.5 V |
|---|---|---|---|
| Voltage Applied To 3-state Output(1): | –0.5 To 5.5 V | Storage Temperature (ambient)(3): | –65 To +150 OC |
| Junction Temperature: | +150 OC | ||
| Highlight: | programming ic chips,ic programmer circuit |
||
Power Estimation
Power dissipation in CPLDs can vary substantially depending on the system frequency, design application and output loading. To help reduce power dissipation, each macrocell in a XC9500XL device may be configured for low-power mode (from the default high-performance mode). In addition, unused product-terms and macrocells are automatically deactivated by the software to further conserve power. For a general estimate of ICC, the following equation may be used:
ICC(mA) = MCHS(0.175*PTHS + 0.345) + MCLP(0.052*PTLP + 0.272) + 0.04 * MCTOG(MCHS +MCLP)* f
This calculation was derived from laboratory measurements of an XC9500XL part filled with 16-bit counters and allowing a single output (the LSB) to be enabled. The actual ICC value varies with the design application and should be verified during normal system operation. Figure 1 shows the above estimation in a graphical form. For a more detailed discussion of power consumption in this device, see Xilinx
Absolute Maximum Ratings(2)
| Symbol | Description | Value | Units |
| VCC | Supply voltage relative to GND | –0.5 to 4.0 | V |
| VIN | Input voltage relative to GND(1) | –0.5 to 5.5 | V |
| VTS | Voltage applied to 3-state output(1) | –0.5 to 5.5 | V |
| TSTG | Storage temperature (ambient)(3) | –65 to +150 | oC |
| TJ | Junction temperature | +150 | oC |
Device Part Marking and Ordering Combination Information
