STK0765BF rf power mosfet transistors electrical ic Power Mosfet Transistor Advanced Power MOSFET

: Large Image : STK0765BF rf power mosfet transistors electrical ic Power Mosfet Transistor Advanced Power MOSFET

Product Details:

Place of Origin:	original factory
Brand Name:	Anterwell
Certification:	new & original
Model Number:	STK0765BF

Payment & Shipping Terms:

Minimum Order Quantity:	10pcs
Price:	Negotiate
Packaging Details:	Please contact me for details
Delivery Time:	1 day
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	8700pcs

Contact Now

Detailed Product Description

Drain-source Voltage:	650 V	Gate-source Voltage:	±30 V
Drain Current (Pulsed):	28 A	Drain Power Dissipation:	52 W
Single Pulsed Avalanche Energy:	340 MJ	Storage Temperature Range:	-55~150 °C
Highlight:	npn smd transistor , multi emitter transistor

STK0765BF Advanced Power MOSFET

SWITCHING REGULATOR APPLICATIONS

Features

• High Voltage: BVDSS=650V(Min.)

• Low Crss : Crss=13pF(Typ.)

• Low gate charge : Qg=32nC(Typ.)

• Low RDS(on) :RDS(on)=1.2Ω(Typ.)

Ordering Information

Type NO. Marking Package Code

STK0765BF STK0765 TO-220F-3L

Absolute maximum ratings (Tc=25°C)

Characteristic		Symbol	Rating	Unit
Drain-source voltage		V_DSS	650	V
Gate-source voltage		V_GSS	±30	V
Drain current (DC)	(Tc=25℃)	I_D	7	A
Drain current (DC)	(Tc=100℃)	I_D	4.4	A
Drain current (Pulsed) *		I_DP	28	A
Drain power dissipation		P_D	52	W
Single pulsed avalanche energy ②		E_AS	340	mJ
Avalanche current (Repetitive) ①		I_AR	5.2	A
Repetitive avalanche energy ①		E_AR	13	mJ
Junction temperature		T_J	150	°C
Storage temperature range		T_stg	-55~150	°C

* Limited by maximum junction temperature

Note :

① Repetitive Rating : Pulse Width Limited by Maximum Junction Temperature

② L=10mH, I_AS=7A, V_DD=50V, R_G=25Ω , starting T_J=25℃

Outline Dimensions unit : mm
