SN7407N Hex Buffers / Drivers Electronics Components With Open Collector , High Voltage Outputs

: Large Image : SN7407N Hex Buffers / Drivers Electronics Components With Open Collector , High Voltage Outputs

Product Details:

Place of Origin:	Original
Brand Name:	TI
Certification:	Original Factory Pack
Model Number:	SN7407N

Payment & Shipping Terms:

Minimum Order Quantity:	20pcs
Price:	Negotiation
Packaging Details:	please contact me for details
Delivery Time:	1 Day
Payment Terms:	T/T, Western Union,PayPal
Supply Ability:	5200PCS

Contact Now

Detailed Product Description

Supply Voltage, VCC:	7 V	Input Voltage, VI:	5.5 V
Output Voltage, VO:	30 V	Package Thermal Impedance,:	86 °C/W
Storage Temperature Range, Tstg:	−65 °C To 150°C
Highlight:	chip in electronics , small scale integrated circuits

SN7407N Hex Buffers / Drivers Electronics Components With Open Collector , High Voltage Outputs

SN7407N Hex Buffers / Drivers Electronics Components With Open Collector , High Voltage Outputs ►Convert TTL Voltage Levels to MOS Levels

►High Sink-Current Capability

►Input Clamping Diodes Simplify System Design ►Open-Collector Driver for Indicator Lamps and Relays

►Inputs Fully Compatible With Most TTL Circuits

description/ordering information

These TTL hex buffers/drivers feature high-voltage open-collector outputs for interfacing with high-level circuits (such as MOS) or for driving high-current loads (such as lamps or relays) and also are characterized for use as buffers for driving TTL inputs. The SN5407 and SN7407 have minimum breakdown voltages of 30 V, and the SN5417 and SN7417 have minimum breakdown voltages of 15 V. The maximum sink current is 30 mA for the SN5407 and SN5417 and 40 mA for the SN7407 and SN7417.

These devices perform the Boolean function Y = A in positive logic.
