Product Details:
Payment & Shipping Terms:
|
| Repetitive Peak Reverse Voltage: | 30 V | Forward Continuous Current At T =25℃: | 200 MA |
|---|---|---|---|
| Power Dissipation At T=65℃: | 200 MW | Junction Temperature: | 125 ℃ |
| Ambient Operating Temperature Range: | -55~+125 ℃ | Storage Temperature Range: | -55~+150 ℃ |
| Highlight: | bridge rectifier circuit,signal schottky diode |
||
BAT85 SMALL SIGNAL SCHOTTKY DIODES
Features
• Lead Free Finish/Rohs Compliant (Note1) ("P"Suffix designates Compliant. See ordering information)
• For general purpose applications
• These diodes features very low turn-on voltage and fast switching. These devices are protected by a PN junction guard ring against excessive voltage,such as electrostatic discharges.
• This diode is also available in the Mini-MELF case with type designation LL85.
• Moisture Sensitivity Level 1
MECHANICAL DATA
· Case: Do-35 glass case
· Polarity: Color band denotes cathode end
· Weight: Approx. 0.13 gram
ABSOLUTE RATINGS(LIMITING VALUES)
|
Symbol |
Value |
Unit |
|
|
Repetitive Peak Reverse Voltage |
VR |
30 |
V |
|
Forward Continuous Current at T =25℃ |
IF |
200 |
mA |
|
Repetitive Peak Forward Current at t<1s, ä< 0.5,T=25℃ |
IFM |
300 |
mA |
|
Surge forward current at tp<10mS , T=25℃ |
IFSM |
600 |
mA |
|
Power Dissipation at T=65℃ |
Ptot |
200 |
mW |
|
Junction temperature |
TJ |
125 |
℃ |
|
Ambient Operating temperature Range |
TA |
-55~+125 |
℃ |
|
Storage Temperature Range |
TSTG |
-55~+150 |
℃ |
|
1) Valid provided that leads at a distance of 4mm from case are kept at ambient temperature |
|||
