Detailed Product Description

Emitte-base Voltage (IC = 0):	5 V	Collector Current:	4 A
Collector Peak Current:	6 A	Base Current:	0.1 A
Storage Temperature:	-65 To 150 °C	Max. Operating Junction Temperature:	150 °C
Highlight:	power mosfet ic , silicon power transistors

Complementary power Darlington transistors

Features BD682G npn darlington power transistor Power Mosfet Transistor Plastic Medium−Power Silicon PNP Darlingtons

■ Good hFE linearity

■ High fT frequency

■ Monolithic Darlington configuration with integrated antiparallel collector-emitter diode

Applications

■ Linear and switching industrial equipment

Description

The devices are manufactured in planar base island technology with monolithic Darlington configuration.

Absolute maximum ratings

Symbol	Parameter		Value			Unit
		NPN	BD677 BD677A	BD679 BD679A	BD681
		PNP	BD678 BD678A	BD680 BD680A	BD682
V_CBO	Collector-base voltage (IE = 0)		60	80	100	V
V_CEO	Collector-emitter voltage (IB = 0)
V_EBO	Emitte-base voltage (IC = 0)		5			V
I_C	Collector current		4			A
I_CM	Collector peak current		6			A
I_B	Base current		0.1			A
P_TOT	Total dissipation at T_case = 25°C		40			W
T_stg	Storage temperature		-65 to 150			°C
T_J	Max. operating junction temperature		150			°C

Note: For PNP types voltage and current values are negative

Internal schematic diagram

BD682G npn darlington power transistor Power Mosfet Transistor Plastic Medium−Power Silicon PNP Darlingtons

Resistive load switching test circuit

BD682G npn darlington power transistor Power Mosfet Transistor Plastic Medium−Power Silicon PNP Darlingtons

Note: For PNP types voltage e current values are negative.

Package mechanical data

BD682G npn darlington power transistor Power Mosfet Transistor Plastic Medium−Power Silicon PNP Darlingtons
