A1302KUA Power Mosfet Transistor Continuous Time Ratiometric Linear Hall Effect Sensors

A1302KUA Power Mosfet Transistor Continuous Time Ratiometric Linear Hall Effect Sensors

Features and Benefits

►Low-noise output

►Fast power-on time

►Ratiometric rail-to-rail output

►4.5 to 6.0 V operation

►Solid-state reliability

►Factory-programmed at end-of-line for optimum performance

►Robust ESD performance

The A1301 and A1302 are continuous-time, ratiometric, linear Hall-effect sensors. They are optimized to accurately provide a voltage output that is proportional to an applied magnetic field. These devices have a quiescent output voltage that is 50% of the supply voltage. Two output sensitivity options are provided: 2.5 mV/G typical for the A1301, and 1.3 mV/G typical for the A1302.

The Hall-effect integrated circuit included in each device includes a Hall sensing element, a linear amplifier, and a CMOS Class A output structure. Integrating the Hall sensing element and the amplifier on a single chip minimizes many of the problems normally associated with low voltage level analog signals.

High precision in output levels is obtained by internal gain and offset trim adjustments made at end-of-line during the manufacturing process.

These features make the A1301 and A1302 ideal for use in position sensing systems, for both linear target motion and rotational target motion. They are wellsuited for industrial applications over extended temperature ranges, from –40°C to 125°C.
