PIC16F59-I/P

Flash-Based, 8-Bit CMOS Microcontroller Series

High-Performance RISC CPU:

• Only 33 single-word instructions to learn

• All instructions are single cycle except for program branches which are two-cycle

• Two-level deep hardware stack

• Direct, Indirect and Relative Addressing modes for data and instructions

• Operating speed: - DC – 20 MHz clock speed - DC – 200 ns instruction cycle time

• On-chip Flash program memory: - 512 x 12 on PIC16F54

- 2048 x 12 on PIC16F57 - 2048 x 12 on PIC16F59

• General Purpose Registers (SRAM): - 25 x 8 on PIC16F54

- 72 x 8 on PIC16F57 - 134 x 8 on PIC16F59

Special Microcontroller Features:

• Power-on Reset (POR)

• Device Reset Timer (DRT)

• Watchdog Timer (WDT) with its own on-chip RC oscillator for reliable operation

• Programmable Code Protection

• Power-Saving Sleep mode

• In-Circuit Serial Programming™ (ICSP™)

• Selectable oscillator options:

- RC: Low-cost RC oscillator

- XT: Standard crystal/resonator

- HS: High-speed crystal/resonator

- LP: Power-saving, low-frequency crystal

• Packages:

- 18-pin PDIP and SOIC for PIC16F54

- 20-pin SSOP for PIC16F54

- 28-pin PDIP, SOIC and SSOP for PIC16F57

- 40-pin PDIP for PIC16F59

- 44-pin TQFP for PIC16F59

Low-Power Features:

• Operating Current: - 170 μA @ 2V, 4 MHz, typical - 15 μA @ 2V, 32 kHz, typical

• Standby Current: - 500 nA @ 2V, typical Peripheral Features:

• 12/20/32 I/O pins: - Individual direction control - High current source/sink

• 8-bit real-time clock/counter (TMR0) with 8-bit programmable prescaler CMOS Technology:

• Wide operating voltage range: - Industrial: 2.0V to 5.5V - Extended: 2.0V to 5.5V

• Wide temperature range: - Industrial: -40°C to 85°C - Extended: -40°C to 125°C

• High-endurance Flash: - 100K write/erase cycles - > 40-year retention
