Product Details:
Payment & Shipping Terms:
|
| DC Supply Voltage: | −0.5 To +7.0 V | DC Input Voltage: | −0.5 ≤ VI ≤ +7.0 V |
|---|---|---|---|
| DC Input Diode Current: | -50 MA | DC Output Source/Sink Current: | ±50 MA |
| DC Ground Current Per Ground Pin: | ±100 MA | Storage Temperature Range: | −65 To +150 °C |
| Highlight: | power mosfet ic,silicon power transistors |
||
MC74LCX245 Low-Voltage CMOS Octal Transceiver
With 5 V−Tolerant Inputs and Outputs (3−State, Non−Inverting)
The MC74LCX245 is a high performance, non−inverting octal transceiver operating from a 2.0 to 5.5 V supply. High impedance TTL compatible inputs significantly reduce current loading to input drivers while TTL compatible outputs offer improved switching noise performance. A VI specification of 5.5 V allows MC74LCX245 inputs to be safely driven from 5 V devices if VCC is less than 5.0 V. The MC74LCX245 is suitable for memory address driving and all TTL level bus oriented transceiver applications.
Current drive capability is 24 mA at both A and B ports. The Transmit/Receive (T/R) input determines the direction of data flow through the bi−directional transceiver. Transmit (active−HIGH) enables data from A ports to B ports; Receive (active−LOW) enables data from B to A ports. The Output Enable input, when HIGH, disables both A and B ports by placing them in a HIGH Z condition.
Features
• Designed for 2.0 to 5.5 V VCC Operation
• 5 V Tolerant − Interface Capability With 5 V TTL Logic
• Supports Live Insertion and Withdrawal
• IOFF Specification Guarantees High Impedance When VCC = 0 V
• LVTTL Compatible
• LVCMOS Compatible
• 24 mA Balanced Output Sink and Source Capability
• Near Zero Static Supply Current in All Three Logic States (10 A)
Substantially Reduces System Power Requirements
• Latchup Performance Exceeds 500 mA
• ESD Performance: Human Body Model >2000 V
Machine Model >200 V
• NLV Prefix for Automotive and Other Applications Requiring Unique Site and
Control Change Requirements; AEC−Q100 Qualified and PPAP Capable
• These Devices are Pb−Free, Halogen Free/BFR Free and are RoHS Compliant
MAXIMUM RATINGS
| Symbol | Parameter | Value | Condition | Unit |
| VCC | DC Supply Voltage | −0.5 to +7.0 | V | |
| VI | DC Input Voltage | −0.5 ≤ VI ≤ +7.0 | V | |
| VO | DC Output Voltage | −0.5 ≤ VO ≤ +7.0 | Output in 3−State | V |
| −0.5 ≤ VO ≤ VCC + 0.5 | Output in HIGH or LOW State (Note 1) | V | ||
| IIK | DC Input Diode Current | −50 | VI< GND | mA |
| IOK | DC Output Diode Current | −50 | VO < GND | mA |
| +50 | VO > VCC | mA | ||
| IO | DC Output Source/Sink Current | ±50 | mA | |
| ICC | DC Supply Current Per Supply Pin | ±100 | mA | |
| IGND | DC Ground Current Per Ground Pin | ±100 | mA | |
| TSTG | Storage Temperature Range | −65 to +150 | °C | |
| MSL | Moisture Sensitivity | Level 1 |
Stresses exceeding Maximum Ratings may damage the device. Maximum Ratings are stress ratings only. Functional operation above the Recommended Operating Conditions is not implied. Extended exposure to stresses above the Recommended Operating Conditions may affect device reliability.
1. IO absolute maximum rating must be observed.
MARKING DIAGRAMS
Pinout (Top View)
Logic Diagram
