LE28C1001AM-12MPB SOP-32 Circuit Board Chips IC Chip Optocoupler with Phototransistor Output

CNY65A

Optocoupler, Phototransistor Output, Very High Isolation Voltage

Features

• Rated isolation voltage (RMS includes DC) VIOWM = 1000 VRMS (1450 V peak)

• Rated recurring peak voltage (repetitive) VIORM = 1000 VRMS

• Thickness through insulation ≥ 3 mm

• Creepage current resistance according to VDE 0303/IEC 60112 Comparative Tracking Index: CTI ≥ 200 • Lead-free component

• Component in accordance to RoHS 2002/95/EC and WEEE 2002/96/EC

Agency Approvals

• UL1577, File No. E76222 System Code H,J &K, Double Protection

• DIN EN 60747-5-2 (VDE0884) DIN EN 60747-5-5 pending

• VDE related features:

• Rated impulse voltage (transient overvoltage) VIOTM = 8 kV peak

• Isolation test voltage (partial discharge test voltage) Vpd = 2.8 kV peak

Applications

Circuits for safe protective separation against electrical shock according to safety class II (reinforced isolation): For appl. class I - IV at mains voltage ≤ 300 V For appl. class I - IV at mains voltage ≤ 600 V For appl. class I - III at mains voltage ≤ 1000 V according to DIN EN 60747-5-2(VDE0884)/ DIN EN 60747- 5-5 pending, table 2, suitable for: Switch-mode power supplies, line receiver, computer peripheral interface, microprocessor system interface.

Description

The CNY64/ CNY65/ CNY66 consist of a phototransistor optically coupled to a gallium arsenide infraredemitting diode in a 4-pin plastic package. The single components are mounted opposite one another, providing a distance between input and output for highest safety requirements of > 3 mm.
