HCF4060BE

COUNTER/DIVIDER AND OSCILLATOR 14-STAGE RIPPLE CARRY BINARY

. MEDIUM-SPEED OPERATION

. COMMON RESET

. FULLY STATIC OPERATION

. BUFFERED INPUTS AND OUTPUTS

. QUIESCENT CURRENT SPECIFIED TO 20V

  FOR HCC DEVICE

. 5V, 10V AND 15V PARAMETRIC RATINGS

.INPUT CURRENT OF 100nA AT 18V AND 25o C FOR HCC DEVICE

. 1005 TESTED FOR QUIESCENT CURRENT

. MEETS ALL REQUIREMENTS OF JEDECTENTATIVE STANDARD N. 13A, ” STANDARD SPECIFICATIONS FOR DESCRIPTION OF ’ B ’ SERIES CMOS DEVICES ”

DESCRIPTION

The HCC4060B (extended temperature range) and HCF4060B (intermediate temperature range) are monolithic integrated circuit, available in 16-lead dual in line plastic or ceramic package and plastic micropackage. The HCC/HCF4060B consist of an oscillator section and 14 ripple carry binary counter stages. The oscillator configuration allows design of either RC or crystal oscillator circuits. A RESET input is provided which reset the counter to the all 0’s state and disables oscillator. A high level on the RESET line accmplishes the reset function. All counter stages are master slave flip-flops. The state of the counter is advanced one step in binary order on the negative transition of φ1 (and φ0). All inputs and outputs are fully buffered. Schmitt trigger action on the clock lin permits unlimited clock rise and fall time.
