MB15026GF

SERIAL INPUT PLL FREQUENCY SYNTHESIZER ic internal circuit

FEATURES

• High operating frequency: fIN MAX=1.1GHz (VIN MIN=10dBm)

• Pulse swallow function: 64/65 or 128/129

• Low supply current: ICC=8mA typ.

• Serial input 18-bit programmable divider consisting of:

— Binary 7-bit swallow counter: 0 to 127

— Binary 11-bit programmable counter: 16 to 2047

• Serial input 15-bit programmable reference divider consisting of: — Binary 14-bit programmable reference counter: 8 to 16383

— 1-bit switch counter (SW) sets divide ratio of prescaler

• On-chip analog switch achieves fast lock up time

• 2 types of phase detector output — On-chip charge pump (Bipolar type)

— Output for external charge pump

• Wide operating temperature:

–40
C to +85
C

• 16-pin Plastic DIP Package (Suffix: —P) 16-pin Plastic Flat Package (Suffix: —PF)
