2KBP06M Rectifier Diode Glass Passivated Single - Phase Bridge Rectifier

: Large Image : 2KBP06M Rectifier Diode Glass Passivated Single - Phase Bridge Rectifier

Product Details:

Place of Origin:	original factory
Brand Name:	Anterwell
Certification:	new & original
Model Number:	2KBP06M

Payment & Shipping Terms:

Minimum Order Quantity:	20pcs
Price:	Negotiate
Packaging Details:	Please contact me for details
Delivery Time:	1 day
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	8400pcs

Contact Now

Detailed Product Description

Maximum Repetitive Peak Reverse Voltage:	600 V	Maximum RMS Voltage:	420 V
Maximum DC Blocking Voltage:	600 V	Max. Average Forward Output Rectified Current:	2.0 A
Rating For Fusing (t < 8.3 Ms):	15 A2s	Operating Junction And Storage Temperature:	- 55 To + 165 °C
Highlight:	diode rectifier circuit , signal schottky diode

2KBP06M Rectifier Diode Glass Passivated Single - Phase Bridge Rectifier

Stock Offer (Hot Sell)

Part No.

Quantity

Brand

D/C

Package

PZT2222A	81000	FSC	13+	SOT-223
PZT2222AT1G	54000	ON	16+	SOT-223
PZTA42T1G	35000	ON	16+	SOT-223
PZTA92T1G	36000	ON	13+	SOT-223
Q13FC1350000400	38000	EPSON	13+	SMD
QFET-3000-TR1G	16165	AVAGO	16+	SOT-343
R1LP0408CSB-7LI	3865	RENESAS	16+	TSOP-32
R2A15120FA	5054	RENESAS	14+	QFP48
R2A15908SP	7631	RENESAS	16+	SOP-28
R4363	8626	HARRIS	16+	TO-263
R5F100LEAFA#V0	1933	RENESAS	12+	LQFP-64
RA30H2127M	1228	MITSUBISH	12+	H2S
RA35H1516M	1255	MITSUBISH	15+	DIP
RB160L-90 TE25	65000	ROHM	15+	SOD-106
RB160M-60	155000	ROHM	14+	SOD-123
RB450F	12000	ROHM	14+	SOT-323
RB551V-30	9000	ROHM	16+	SOD-323
RC4558DR	31000	TI	16+	SOP-8
RCLAMP0504F.TCT	64000	SEMTECH	15+	SOT-363
RCLAMP0504S.TCT	65000	SEMTECH	15+	SOT23-6
RCLAMP0524P.TCT	158000	SEMTECH	13+	SLP2510P8
RD06HVF1	2253	MITSUBISH	14+	TO-220
REF03GS	5373	ADI	16+	SOP-8
REF192FSZ	4252	AD	13+	SOP-8
REF192GSZ	6359	AD	16+	SOP-8
REF195GSZ	3984	AD	16+	SOP-8
REF198FS-REEL	5545	AD	06+	SOP-8
REF3030AIDBZR	4334	TI	15+	SOT-23
REF3040AIDBZR	4160	TI	15+	SOT-23
REF5020AIDR	3759	TI	16+	SOP-8

2KBP005M thru 2KBP10M, 3N253 thru 3N259

Glass Passivated Single-Phase Bridge Rectifier

FEATURES

• UL recognition file number E54214

• Ideal for printed circuit board

• High surge current capability

• High case dielectric strength

• Solder dip 260 °C, 40 s

• Component in accordance to RoHS 2002/95/EC and WEEE 2002/96/EC

TYPICAL APPLICATIONS

General purpose use in ac-to-dc bridge full wave rectification for switching power supply, home appliances, office equipment, and telecommunication applications.

MECHANICAL DATA

Case: KBPM

Epoxy meets UL 94V-0 flammability rating

Terminals: Silver plated leads, solderable per J-STD-002 and JESD22-B102

E4 suffix for consumer grade

Polarity: As marked on body

MAXIMUM RATINGS (T_A = 25 °C unless otherwise noted)

PARAMETER	SYMBOL	2KBP 005M	2KBP 01M	2KBP 02M	2KBP 04M	2KBP 06M	2KBP 08M	2KBP 10M	UNIT
PARAMETER	SYMBOL	3N253	3N254	3N255	3N256	3N257	3N258	3N259	UNIT
Maximum repetitive peak reverse voltage	V_RRM	50	100	200	400	600	800	1000	V
Maximum RMS voltage	V_RMS	35	70	140	280	420	560	700	V
Maximum DC blocking voltage	V_DC	50	100	200	400	600	800	1000	V
Max. average forward output rectified current at T_A = 55 °C	I_F(AV)	2.0							A
Peak forward surge current single half sine-wave superimposed on rated load	I_FSM	60							A
Rating for fusing (t < 8.3 ms)	I²t	15							A²s
Operating junction and storage temperature range	T_J, T_STG	- 55 to + 165							°C
