Quadruple operationl amplifiers common integrated circuits LM324ADR

Quadruple operationl amplifiers common integrated circuits LM324ADR

► 2-kV ESD Protection for:

− LM224K, LM224KA

− LM324K, LM324KA

− LM2902K, LM2902KV, LM2902KAV

►Wide Supply Ranges

− Single Supply . . . 3 V to 32 V (26 V for LM2902)

− Dual Supplies . . .
1.5 V to
16 V (
13 V for LM2902)

►Low Supply-Current Drain Independent of Supply Voltage . . . 0.8 mA Typ

►Common-Mode Input Voltage Range Includes Ground, Allowing Direct Sensing Near Ground

►Differential Input Voltage Range Equal to Maximum-Rated Supply Voltage . . . 32 V (26 V for LM2902)

►Open-Loop Differential Voltage Amplification . . . 100 V/mV Typ
►Internal Frequency Compensation

description/ordering information

These devices consist of four independent high-gain frequency-compensated operational amplifiers that are designed specifically to operate from a single supply over a wide range of voltages. Operation from split supplies also is possible if the difference between the two supplies is 3 V to 32 V (3 V to 26 V for the LM2902), and VCC is at least 1.5 V more positive than the input common-mode voltage. The low supply-current drain is independent of the magnitude of the supply voltage.

Applications include transducer amplifiers, dc amplification blocks, and all the conventional operational-amplifier circuits that now can be more easily implemented in single-supply-voltage systems. For example, the LM124 can be operated directly from the standard 5-V supply that is used in digital systems and provides the required interface electronics, without requiring additional ±15-V supplies.

schematic (each amplifier)
