HEF4069UBT Electronics Components LOGIC GATE | HEX INVERTER | CMOS

: Large Image : HEF4069UBT Electronics Components LOGIC GATE | HEX INVERTER | CMOS

Product Details:

Place of Origin:	original factory
Brand Name:	Anterwell
Certification:	new & original
Model Number:	HEF4069UBT

Payment & Shipping Terms:

Minimum Order Quantity:	20pcs
Price:	Negotiate
Packaging Details:	Please contact me for details
Delivery Time:	1 day
Payment Terms:	T/T, Western Union, Paypal
Supply Ability:	9200pcs

Contact Now

Detailed Product Description

Supply Voltage:	-0.5 To +18 V	Input Clamping Current:	±10 MA
Input Voltage:	-0.5 To VDD + 0.5 V	Output Clamping Current:	±10 MA
Supply Current:	50 MA	Storage Temperature:	-65 To +150℃
Highlight:	chip in electronics , small scale integrated circuits

HEF4069UB Hex inverter

General description

The HEF4069UB is a general purpose hex inverter. Each inverter has a single stage. It operates over a recommended V_DD power supply range of 3 V to 15 V referenced to V_SS (usually ground). Unused inputs must be connected to V_DD, V_SS, or another input.

Features and benefits

Fully static operation
5 V, 10 V, and 15 V parametric ratings
Standardized symmetrical output characteristics
Specified from 40 ℃ to +85 ℃ and 40 ℃ to +125 ℃
Complies with JEDEC standard JESD 13-B

Applications

Oscillator

Limiting values

In accordance with the Absolute Maximum Rating System (IEC 60134).

Symbol	Parameter	Conditions	Min	Max	Unit
V_DD	supply voltage		-0.5	+18	V
I_IK	input clamping current	V_I < 0.5 V or V_I > V_DD+ 0.5 V	-	±10	mA
V_I	input voltage		-0.5	V_DD + 0.5	V
I_OK	output clamping current	V_O < 0.5 V or V_O > V_DD + 0.5 V	-	±10	mA
I_I/O	input/output current		-	±10	mA
I_DD	supply current		-	50	mA
T_stg	storage temperature		-65	+150	℃
T_amb	ambient temperature		-40	+125	℃
P_tot	total power dissipation	T_amb = 40 ℃ to +125 ℃
		DIP14 ^[1]	-	750	mW
		SO14 ^[2]	-	500	mW
		TSSOP14 ^[3]	-	500	mW
P	power dissipation	per output	-	100	mW

[1] For DIP14 packages: above T_amb = 70 ℃, Ptot derates linearly with 12 mW/K.

[2] For SO14 packages: above T_amb = 70 ℃, Ptot derates linearly with 8 mW/K.

[3] For TSSOP14 packages: above T_amb = 60 ℃, Ptot derates linearly with 5.5 mW/K.

Functional diagram

HEF4069UBT Electronics Components LOGIC GATE | HEX INVERTER | CMOS

Pinning information
