PS2805C -4- F3- A Common Ic Chips High Isolation Vol Tage Ac Input

PS2805C-4-F3-A

HIGH ISOLATION VOL TAGE AC INPUT common ic chips

FEATURES

• High isolation voltage

(BV = 2 500 Vr.m.s.)

• Small and thin package

(4, 16-pin SSOP, Pin pitch 1.27 mm)

• High collector to emitter voltage (VCEO : 80 V)

• AC input response

• Ordering number of tape product: PS2805C-1-F3, PS2805C-4-F3

• Pb-Free product

• Safety standards

• UL approved: No. E72422

• CSA approved: No. CA 101391 (CA5A, CAN/CSA-C22.2 60065, 60950)

• BSI approved (BS EN 60065, BS EN 60950) (PS2805C-1 only)

• DIN EN 60747-5-5 (VDE 0884-5) approved (Option

APPLICATIONS

• Programmable logic controllers

• OA equipment

• Measuring instruments

• Hybrid IC

DESCRIPTION

The PS2805C-1 and PS2805C-4 are optically coupled isolators containing a GaAs light emitting diode and an NPN silicon phototransistor in a plastic SSOP for high density applications to realize an excellent cost performance. This package has shield effect to cut off ambient light.

MARKING EXAMPLE
